纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (03-005) - LIGHT INSTAL (BOOM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
930 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC80E00004F1 | [1] | LIGHT | KOBINSTAL,BOOM |
| A1. | YW80S00001F1 | [2] | LIGHT ASSY. | KOB Superseded by part number: 2456R442F1 |
| A2. | 2416T13056 | [2] | BRACKET | KOB |
| A3. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| A4. | 2418R323D11 | [2] | WASHER | KOB |
| A5. | 2418R323D13 | [2] | LOCK WASHER | KOB |
| . . | YB15E00002F2 | [1] | HARNESS ASSY, BOOM | |
| B1. | YN15E01012P1 | [1] | HARNESS | KOB |
| B2. | PY01P01043D4 | [1] | CABLE TIE,4.80mm W x 251mm L | KOB |
