纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-006) - CYLINDER ASSY, BOOM (L.H.) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
874 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB01V00009F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, BOOM (LH) |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER |
| 3. | YB01V00008S003 | [1] | CYLINDER | KOBHEAD |
| 4. | 2438U1109S14 | [1] | BUSHING | KOB |
| 5. | 2438U1105S5 | [1] | SNAP RING | KOBRETAINING |
| 6. | YN01V00106S006 | [1] | RING | KOBBUFFER, FOR F1 ONLY Superseded by part number: YM01V00006S006 |
| 7. | 2438U1105S7 | [1] | RING | KOBU |
| 8. | 2438U1105S8 | [1] | RING | KOBBACK UP |
| 9. | 2438U1105S35 | [1] | RING | KOBWIPER |
| 10. | ZD12G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOB |
| 11. | YR01V00001S011 | [1] | RING | KOBBACK UP |
| 12. | 2441U802S26 | [10] | SCREW | KOBCAP |
| 13. | YB01V00008S013 | [1] | BUSHING | KOBCUSHION |
| 14. | YM01V00006S014 | [1] | SEAL | KOBCUSHION |
| 15. | YN01V00106S015 | [1] | PISTON | KOB |
| 16. | LE01V00006S014 | [1] | RING | KOBSEAL |
| 17. | YN01V00106S017 | [2] | BACK-UP RING | KOB |
| 19. | YN01V00106S019 | [2] | SCRAPER RING | KOBSLIDE |
| 20. | 2438U1946S20 | [1] | SHIM | KOB |
| 21. | YM01V00006S021 | [1] | NUT | KOB |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSET |
| 23. | 2436U330S16 | [1] | BALL | KOB |
| 24. | YB01V00008S024 | [2] | BUSHING | KOB Superseded by part number: YB01V01001P1 |
| 25. | YM01V00006S025 | [4] | RING | KOBWIPER Superseded by part number: 2438U941S3 |
| 26. | YB01V00008S026 | [1] | STRAP | KOBASSY |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 30. | YM01V00006S006 | [1] | RING | KOBBUFFER, FOR F2 ONLY |
| 50. | YB01V00008S050 | [2] | RING | KOBRING,SLIDE |
| . . | YB01V00008R400 | [1] | CYLINDER | KOBREPAIR KIT CONSISTS OF Ref. 1(1), 24(1) |
| . . | YB01V00008R500 | [1] | CYLINDER | KOBCONSISTS OF Ref. 2(1), 24(1) |
| . . | YB01V00008R600 | [1] | REPAIR KIT | KOBPISTON SIDE CONSISTS OF Ref. 14(1), 16(1), 17(2), 19(2), 50(2) |
| . . | YB01V00008R700 | [1] | REPAIR KIT | KOBALL(ROD+PISTON) CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 14(1), 16(1), 17(2), 19(2), 30(1), 50(2), FOR F2 ONLY |
| . . | YN01V00106R100 | [1] | REPAIR KIT | KOBROD SIDE CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 30(1), FOR F2 ONLY |
