纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-007) - CYLINDER ASSY, ARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
473 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB01V00010F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, ARM |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER |
| 3. | YB01V00010S003 | [1] | CYLINDER | KOBHEAD |
| 4. | 2438U999S4 | [1] | BUSHING | KOB |
| 5. | 2438U999S5 | [1] | RING | KOBRETAINING |
| 6. | LQ01V00001S006 | [1] | RING | KOBBUFFER, FOR F1 ONLY Superseded by part number: YM01V00008S006 |
| 7. | 2438U999S7 | [1] | RING | KOBU |
| 8. | 2438U999S8 | [1] | RING | KOBBACK UP |
| 9. | 2438U1135S35 | [1] | RING | KOBWIPER |
| 10. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOB |
| 11. | 2438U1102S12 | [1] | O-RING | KOBBACK UP |
| 12. | ZS23C16075 | [12] | SCREW,Hex Socket Head, M16 x 75mm | KOBCAP |
| 13. | YB01V00010S013 | [1] | BUSHING | KOBCUSHION |
| 14. | LQ01V00005S014 | [1] | SEAL | KOBCUSHION |
| 15. | YM01V00008S015 | [1] | PISTON | KOB |
| 16. | 2438U675S20 | [1] | RING | KOBSEAL |
| 17. | YM01V00008S017 | [2] | RING | KOBBACK-UP |
| 18. | YM01V00008S018 | [2] | SCRAPER RING | KOBSLIDE |
| 19. | 2438U675S28 | [2] | RING | KOBSLIDE |
| 20. | YM01V00008S020 | [1] | SHIM | KOB |
| 21. | 2438U999S21 | [1] | SET SCREW | KOBSET |
| 22. | 2436U330S16 | [1] | BALL | KOB |
| 23. | YB01V00010S023 | [1] | BUSHING | KOBCUSHION |
| 24. | LQ01V00007S025 | [1] | SEAL | KOBCUSHION |
| 25. | 2438U1104S25 | [2] | STOP | KOB |
| 26. | 2438U1948S27 | [1] | RING | KOBRETAINING |
| 27. | 2438U1948S28 | [2] | BUSHING | KOB |
| 28. | 2438U1102S31 | [4] | SEAL | KOBWIPER |
| 29. | YM01V00008S029 | [1] | STRAP | KOBASSY |
| 30. | YM01V00008S030 | [1] | STRAP | KOB |
| 31. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 32. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 33. | YM01V00008S006 | [1] | RUBBER BLOCK | KOBRING, BUFFER, FOR F2 ONLY |
| . . | YB01V00010R100 | [1] | REPAIR KIT | KOBREPAIR KIT ROD SIDE CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 33(1), FOR F2 ONLY |
| . . | YM01V00008R200 | [1] | KIT | KOBPISTON SIDE CONSISTS OF Ref. 16(1), 17(2), 18(2), 19(2) |
| . . | YB01V00010R300 | [1] | REPAIR KIT | KOBALL (ROD+PISTON) CONSISTS OF Ref. 7(1), 8(1), 9(1), 10(1), 11(1), 16(1), 17(2), 18(2), 19(2), 33(1), FOR F2 ONLY |
| . . | YB01V00010R400 | [1] | CYLINDER | KOBCONSISTS OF Ref. 1(1), 27(1) |
