纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-011) - PUMP ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
535 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB10V00004F1 | [1] | PUMP ASSY | |
| . . | YB10V00004F2 | [1] | PUMP ASSY | |
| . . | YB10V00004F3 | [1] | PUMP ASSY | |
| 10. | YW10V00003S702 | [2] | O-RING | KOBFOR F2 & F3 ONLY |
| 11. | YX10V00003S011 | [2] | O-RING | KOBFOR F2 & F3 ONLY |
| 12. | YX10V00003S012 | [1] | O-RING | KOBFOR F2 & F3 ONLY |
| 13. | YX10V00003S013 | [2] | GASKET | KOBFOR F2 & F3 ONLY |
| 14. | YX10V00003S014 | [2] | GASKET | KOBFOR F2 & F3 ONLY |
| 15. | YX10V00003S015 | [18] | O-RING,1.9mm Thk x 8.8mm ID, 75 Duro | KOBFOR F2 & F3 ONLY |
| 16. | YT10V00003S710 | [2] | O-RING | KOBFOR F2 & F3 ONLY |
| 17. | YT10V00003S708 | [4] | O-RING | KOBFOR F2 & F3 ONLY |
| 18. | YW10V00003S732 | [2] | O-RING | KOBFOR F2 & F3 ONLY |
| 19. | YB10V00004S019 | [1] | OIL SEAL | KOBFOR F3 ONLY |
| 111. | YB10V00004S111 | [1] | SHAFT | KOB |
| 113. | YB10V00004S113 | [1] | SHAFT | KOB |
| 116. | YX10V00003S116 | [1] | GEAR | KOB |
| 123. | YB10V00004S123 | [2] | BEARING | KOBROLLER Superseded by part number: 2437U188S123 |
| 124. | YB10V00004S124 | [2] | BEARING ASSY | KOBNEEDLE |
| 127. | YW10V00003S127 | [4] | SPACER | KOB |
| 141. | NSS | [2] | NOT SERVICED SEPARATELY | CONBLOCK, CYLINDER |
| 153. | YB10V00004S153 | [2] | PLATE | KOB Superseded by part number: EZ10V00008S153 |
| 156. | YW10V00005S156 | [2] | BUSHING | KOB |
| 157. | 2437U188S157 | [18] | SPRING | KOB |
| 211. | 2437U188S211 | [2] | PLATE | KOBSHOE |
| 251. | 2437U188S251 | [1] | PLATE | KOBSUPPORT |
| 252. | YX10V00003S252 | [1] | SUPPORT | KOB |
| 261. | YB10V00004S261 | [1] | BODY | KOBSEAL |
| 262. | YX10V00003S262 | [1] | COVER | KOBSEAL |
| 271. | 2437U188S271 | [2] | CASING | KOB |
| 312. | YX10V00003S312 | [1] | BLOCK | KOBVALVE |
| 401. | 2437U188S401 | [8] | CAPSCREW | KOBSCREW CAP |
| 406. | ZS23C06016 | [8] | SCREW,Hex Socket Head, M6 x 16mm | KOBCAP Superseded by part number: ZS28C06016 |
| 466. | 2441U667S466 | [2] | PLUG | KOB |
| 467. | 2441U436S468 | [4] | PLUG | KOB |
| 490. | 2441U722S490 | [15] | PLUG | KOB |
| 532. | YX10V00003S532 | [2] | PISTON | KOBSERVO |
| 534. | 2437U188S534 | [2] | POPPET | KOBSTOPPER |
| 535. | 2437U188S535 | [2] | STOP | KOB |
| 702. | ZD12G03000 | [2] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBFOR F1 ONLY |
| 710. | ZD12G08500 | [2] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBFOR F1 ONLY |
| 711. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBFOR F1 ONLY |
| 717. | ZD12G12000 | [2] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOBFOR F1 ONLY |
| 719. | ZD12G11500 | [2] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBFOR F1 ONLY |
| 724. | ZD12P00800 | [18] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBFOR F1 ONLY |
| 725. | ZD12P01100 | [2] | O-RING | KOBFOR F1 ONLY |
| 728. | ZD12P01800 | [4] | O-RING | KOBFOR F1 ONLY |
| 732. | ZD12P01600 | [2] | O-RING | KOBFOR F1 ONLY |
| 774. | 2441U267S774 | [1] | GASKET | KOBOIL SEAL, FOR F1 & F2 ONLY Superseded by part number: YB10V00004S019 |
| 789. | ZD85P01600 | [2] | RING | KOBBACK UP |
| 792. | ZD85G03000 | [2] | BACK-UP RING | KOB |
| 808. | ZN12C16010 | [4] | NUT | KOB |
| 824. | ZR16X03500 | [2] | RING | KOBRETAINING |
| 885. | 2441U436S885 | [2] | PIN | KOB |
| 886. | ZP26D06014 | [4] | PIN | KOBSPRING |
| 901. | ZS91C01000 | [2] | BOLT | KOBEYE |
| 953. | 2437U188S953 | [2] | CAP,M10 x 20mm | KOBSETSCREW |
| 954. | 2437U188S954 | [2] | SCREW | KOBSET |
| 983. | 2437U407S983 | [2] | RIVET | KOBPIN |
| . . | YB10V00004R100 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 151(9), 152(9) Superseded by part number: YW10V00003S011 |
| . . | YB10V00004R200 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 531(1), 548(1) |
| . . | YX10V00003R200 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 141(1), 313(1) |
| . . | YX10V00003R300 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 141(1), 314(1) |
| . . | YX10V00003R400 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 212(1), 214(1) |
