| . . | YB30V00011F1 | [1] | CONTROL VALVE | KOBASSY |
| 101. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 155. | YW30V00001S155 | [3] | PLUG | KOB |
| 156. | YN30V00001S156 | [3] | PLUG | KOB Superseded by part number: YW30V00001S156 |
| 158. | YN30V00001S158 | [1] | PLUG | KOB |
| 162. | ZD12G03000 | [17] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 163. | ZD12P01500 | [3] | O-RING | KOB |
| 164. | ZD12P01800 | [3] | O-RING | KOB |
| 166. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 168. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 201. | 2436U1265S201 | [7] | COVER | KOBSPRING Superseded by part number: 2436U2631S201 |
| 202. | LP30V01003F1 | [1] | COVER | KOBASSY |
| 204. | YN30V00021S207 | [4] | COVER | KOBSPRING |
| 206. | 2436U1265S203 | [8] | COVER | KOBSPOOL |
| 211. | YX30V00009F1 | [2] | LOCK VALVE | KOBASSY, SEE FIG. 07-048 |
| 214. | YX20V01001S214 | [2] | PLATE | KOB Superseded by part number: YX30V00002S214 |
| 262. | YY30V00031S262 | [12] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 265. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 272. | ZS23C12025 | [8] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW CAP |
| 273. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBCAP |
| 302. | YB30V00011S302 | [1] | SPOOL | KOBASSY |
| 305. | YW30V00006S305 | [1] | SPOOL | KOB Superseded by part number: YW30V00006R150 |
| 306. | YX30V00011S306 | [2] | REPAIR KIT | KOBSPOOL Superseded by part number: YX30V00011R130 |
| 308. | YW30V00001S308 | [1] | SPOOL | KOB Superseded by part number: YW30V00001R160 |
| 309. | LP30V00004S312 | [2] | REPAIR KIT | KOBSPOOL Superseded by part number: LP30V00004R120 |
| 324. | YX30V00011S324 | [3] | SPRING | KOB |
| 325. | YN30V00001S325 | [8] | SPRING | KOB |
| 326. | YN30V00001S326 | [6] | SPRING | KOB |
| 327. | YN30V00001S327 | [2] | SPRING | KOB |
| 328. | YX30V00011S328 | [1] | SPRING | KOB |
| 329. | 2436U1265S322 | [4] | SPRING | KOB |
| 332. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOBSPACER |
| 337. | 2436U1265S335 | [10] | STOP | KOB |
| 338. | YN30V00001S338 | [2] | STOP | KOB |
| 512. | 2436U1265S511 | [11] | POPPET | KOB |
| 513. | YW30V00001S513 | [2] | POPPET | KOB |
| 514. | YW30V00001S514 | [2] | POPPET | KOB |
| 522. | 2436U1265S521 | [13] | SPRING | KOB |
| 524. | YW30V00001S524 | [2] | SPRING | KOB |
| 552. | YN30V00001S552 | [14] | PLUG | KOB Superseded by part number: YN30V00021S552 |
| 556. | YW30V00001S556 | [2] | PLUG | KOB |
| 562. | ZD12P02000 | [16] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 601. | YN22V00001F4 | [1] | PRESSURE RELIEF VALVE | KOBASSY, MAIN, SEE FIG. 07-027 Superseded by part number: YN22V00001F8 |
| 602. | YN22V00002F1 | [3] | VALVE | KOBASSY, PORT RELIEF, SEE FIG. 07-028 |
| 603. | YN22V00002F9 | [3] | VALVE | KOBASSY, PORT RELIEF, SEE FIG. 07-029 |
| 973. | ZS23C14110 | [7] | SET SCREW,Hex Socket Head, M14 x 110mm | KOBCAP |
| 974. | ZS23C14075 | [1] | CAPSCREW,Hex Socket Head, M14 x 75mm | KOBSCREW CAP |
| . . | YB30V00003R100 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 301(1), 324(1), 329(1), 332(2), 333(1), 337(1) |
| . . | YB30V00011R110 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 302(1), 324(1), 329(1), 332(2), 333(1), 337(1) |
| . . | YB30V00011R100 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 303(1), 324(1), 329(1), 332(2), 333(1), 337(1) |
| . . | YB30V00003R120 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 304(1), 328(1), 329(1), 332(2), 333(1), 337(1) |
| . . | YW30V00006R150 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 305(1), 325(1), 326(1), 332(2), 333(1), 337(1) |
| . . | YX30V00011R130 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 306(1), 325(1), 327(1), 332(2), 333(1), 338(1) |
| . . | YX30V00011R140 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 307(1), 325(1), 326(1), 332(2), 333(1), 337(1) |
| . . | YW30V00001R160 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 308(1), 325(1), 326(1), 332(2), 333(1), 337(1) |
| . . | LP30V00004R120 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 309(1), 325(1), 326(1), 332(2), 333(1), 337(1) |
| . . | YB30V00010R190 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF Ref. 310(1), 325(1), 326(1), 332(2), 333(1), 337(1) |
