| 1. |
455346R21
|
[1] |
PIN
|
IH
ASSY, lock, consists of Superseded by part number: 237924A1
|
| 2. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING Superseded by part number: 237924A1
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X
|
| 4. |
80711
|
[3] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8 ptf short 65D lub
|
| 5. |
660484R21
|
[1] |
FORK
|
IH
YOKE ASSY, w/Q.A. pin, includes ref no. 1 Superseded by part number: 8803645
|
| 6. |
660116R91
|
[3] |
NUT
|
IH
KIT, cross repair Superseded by part number: 84355326
|
| . . |
495962R1
|
[12] |
RING
|
IH
snap
|
| 7. |
ZA550487
|
[1] |
YOKE
|
IH
W/SHAFT, square
|
| . . |
577247R1
|
[1] |
LOCK PIN,3/8" x 2", Slotted
|
IH
Pin, 3/8" x 2", Slotted Superseded by part number: 438-32432
|
| 8. |
96348C1
|
[2] |
NYLON BEARING
|
IH
shield (replaces ZA017167 )
|
| 9. |
ZA550483
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHIC, outer
|
| . . |
ZA017150
|
[1] |
PRODUCT GRAPHIC, warning
|
|
| 10. |
ZA550484
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHIC, inner
|
| 11. |
210605C1
|
[1] |
SET SCREW
|
IH
1/2-20 x 1 socket-hd set
|
| . . |
114496
|
[1] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, 1/2-NF pln jam type 5 Superseded by part number: 124934
|
| 12. |
96352C1
|
[1] |
YOKE
|
IH
pinned (replaces ZA017247 )
|
| 13. |
660489R1
|
[1] |
YOKE
|
IH
splined Superseded by part number: 29212
|
| 14. |
674737R12
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHICS, pto brg box
|
| . . |
88574
|
[2] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd
|
NH
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
ZA740950
|
[1] |
DECAL
|
CAS
PRODUCT GRAPHIC, warning Superseded by part number: ZA211862
|
| . . |
ZA014839
|
[1] |
PRODUCT GRAPHIC, caution
|
|
| 15. |
UA20551
|
[1] |
RING
|
IH
propeller shaft bearing snap
|
| 16. |
584148R91
|
[1] |
BEARING ASSY,35mm ID x 72mm OD x 25mm W
|
IH
BEARING ASSY, propeller shaft front Superseded by part number: 9808112
|
| 17. |
662022R1
|
[1] |
BOX
|
IH
bearing (replaces 622022R1 )
|
| 18. |
ZA550493
|
[1] |
SHAFT
|
IH
JOINT ASSY, yoke & tube
|
| 19. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4 UNF less ball check lub Superseded by part number: 88775
|
| 20. |
597559R1
|
[4] |
RETAINER
|
IH
RING, bearing retainer (replaces ZA017169 )
|
| 21. |
ZA550494
|
[1] |
SHIELD
|
IH
ASSY, inner
|
| 22. |
ZA550495
|
[1] |
SHIELD
|
IH
ASSY, outer
|
| 23. |
ZA550492
|
[1] |
YOKE
|
IH
W/SHAFT, square
|
| 24. |
87569
|
[2] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4 45D taper drive thd lub
|
| 25. |
674862R2
|
[1] |
YOKE
|
IH
flanged
|
| 26. |
674733R1
|
[1] |
SPACER
|
IH
BUSHING, pedestal
|
| . . |
189314
|
[1] |
BOLT,Hex, 1/2" - 13 x 4 3/4", Gr 5
|
IH
1/2 x 4-3/4 type 5 Superseded by part number: 113-432, 413-876
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
20601R1
|
[2] |
WASHER
|
IH
.531 x 1.250 x .105 Superseded by part number: 495-81287
|
| 27. |
674734R1
|
[1] |
BRACKET
|
IH
PIVOT ASSY, bracket
|
| . . |
280954
|
[1] |
NUT,3/4"-10, G5
|
NH
|
| . . |
473873R1
|
[1] |
LOCK NUT,3/4"-16, GB
|
IH
NUT, 3/4-16 MF two way lock, used on stud w/NF threads Superseded by part number: 86528769
|
| . . |
474848R1
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex lock Superseded by part number: 231-4218
|
| 28. |
674729R1
|
[1] |
RING
|
IH
PEDESTAL ASSY, power take-off
|
| . . |
21395R1
|
[1] |
SCREW,Hex, 1/2"-13 x 5 1/4", G5
|
IH
BOLT, 1/2 x 5-1/4 type 5 Superseded by part number: 280290
|
| 29. |
674732R1
|
[2] |
SPACER
|
IH
BUSHING, pedestal
|
| 30. |
96353C1
|
[1] |
BEARING
|
IH
shield (replaces ZA017156 )
|
| 31. |
ZA550409
|
[1] |
JOINT ASSY.
|
IH
SHAFT ASSY, front Superseded by part number: 210553C92
|
| 32. |
ZA550490
|
[1] |
SHAFT
|
IH
ASSY, front half
|
| 33. |
ZA550491
|
[1] |
SHAFT
|
IH
ASSY, rear half
|
