凯斯零件查询(445) - INTERNATIONAL HARVESTER RECTANGULAR BALER (NORTH AMERICA) (1/76-12/88) (A-57[A]) - FOUR COIL WIRE CONTAINER FOR WIRE BALER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
455346R21
|
[1] |
PIN
|
IH
ASSY, lock, consists of Superseded by part number: 237924A1
|
| 2. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING Superseded by part number: 237924A1
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X
|
| 4. |
80711
|
[2] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8 PTF SHORT 65D lub
|
| 5. |
568100R92
|
[1] |
YOKE
|
IH
ASSY, w/Q.A. pin, includes ref no. 1 Superseded by part number: 568100R93
|
| 6. |
200464C91
|
[2] |
PACKAGE
|
IH
KIT, cross repair Superseded by part number: 84355319
|
| . . |
576420R1
|
[8] |
RING
|
IH
snap
|
| 7. |
ZA550413
|
[1] |
YOKE
|
IH
& SHAFT ASSY, retangular
|
| 8. |
ZA017169
|
[2] |
RING, bearing retaining
|
|
| 9. |
ZA550446
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHIC, outer
|
| . . |
ZA017150
|
[1] |
PRODUCT GRAPHIC, warning
|
|
| 10. |
ZA550482
|
[1] |
SHIELD
|
IH
inner
|
| 11. |
ZA017167
|
[2] |
BEARING, shield
|
|
| 12. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4 UNF less ball check lub Superseded by part number: 88775
|
| 13. |
ZA550445
|
[1] |
YOKE
|
IH
& TUBE
|
| 14. |
663101R92
|
[1] |
YOKE
|
IH
flanged
|
| 15. |
87569
|
[2] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4 45D taper drive thd lub
|
| 16. |
ZA550411
|
[1] |
JOINT
|
IH
ASSY, drive, tractor half
|
| 17. |
ZA550412
|
[1] |
JOINT
|
IH
ASSY, drive, implement half
|
