纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-023) - CASE ASSY, GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
167 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB46W00001F1 | [1] | CASE | KOBASSY, GEAR Superseded by part number: YB46W00001F2 |
| . . | YB46W00001F2 | [1] | GEAR | KOBCASE ASSY |
| 10. | NSS | [1] | NOT SERVICED SEPARATELY | CONSHAFT, FOR F2 ONLY |
| 12. | ZP26D04020 | [1] | ROLL PIN | KOBSPRING, FOR F2 ONLY |
| 414. | ZS23C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBCAP |
| 435. | YX46W00001S435 | [4] | SOCKET | KOBCAPSCREW |
| 468. | 2441U436S469 | [1] | PLUG | KOB |
| 711. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOB |
| 728. | ZD12P02400 | [1] | O-RING | KOB |
