纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-026) - VALVE ASSY, SWING-REACTIONLESS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
289 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20V00004F1 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YN20V00004F2 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YN20V00004F3 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YN20V00004F4 | [1] | CONTROL VALVE | KOBASSY, SWING-REACTIONLESS |
| 100. | LQ15V00001S100 | [1] | CASE | KOBFOR F1,F2 & F4 ONLY |
| 151. | YW30V00001S157 | [2] | PLUG | KOB |
| 161. | ZD12P01100 | [2] | O-RING | KOB |
| 162. | ZD12P01200 | [2] | O-RING | KOBFOR F1 TO F3 ONLY |
| 163. | ZD12P00600 | [2] | O-RING | KOBFOR F1 TO F3 ONLY |
| 164. | YT10V00003S711 | [2] | O-RING | KOBFOR F4 ONLY |
| 165. | YN01V01006S011 | [2] | O-RING | KOBFOR F4 ONLY Superseded by part number: YN10V01006S011 |
| 171. | ZS23C08055 | [4] | CAPSCREW,Hex Socket Head, M8 x 55mm | KOBSCREW CAP |
| 400. | YN20V00004S400 | [2] | VALVE | KOBASSY, FOR F1 & F4 ONLY |
| 401. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 403. | ZD85P02000 | [2] | RING | KOB |
| 404. | YN20V00004S404 | [2] | VALVE | KOBASSY, FOR F2 & F3 ONLY |
| 405. | YN20V00004S405 | [1] | CASE | KOBFOR F3 ONLY Superseded by part number: YN20V00004F3 |
