纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-025) - MOTOR ASSY (PROPELLING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN15V00017F1 | [1] | MOTOR | KOBASSY (PROPELLING) Superseded by part number: YN15V00017F3 |
| . . | YN15V00017F2 | [1] | MOTOR ASSY (PROPELLING) | |
| . . | YN15V00017F3 | [1] | MOTOR | KOBASSY (PROPELLING) |
| 1. | YN15V00017S001 | [1] | BODY | KOBFOR F1 & F3 ONLY |
| 2. | YN15V00017S002 | [1] | COVER | KOB |
| 3. | YN15V00017S003 | [1] | BLOCK | KOBCYLINDER |
| 4. | NSS | [1] | NOT SERVICED SEPARATELY | CONRETAINER, SHOE |
| 5. | YN15V00009S005 | [3] | PLATE | KOBFRICTION |
| 6. | YN15V00009S006 | [1] | PISTON | KOBBRAKE |
| 7. | YN15V00009S007 | [4] | PLATE | KOBSEPARATOR |
| 8. | YN15V00017S008 | [1] | PLATE | KOBVALVE |
| 9. | YN15V00017S009 | [1] | SHAFT | KOB |
| 10. | YN15V00017S010 | [1] | COUPLING | KOB |
| 13. | YN15V00017S013 | [1] | SEAT | KOBSPRING |
| 15. | YN15V00009S015 | [1] | RING | KOBFOR F1 ONLY Superseded by part number: YN15V00017S062 |
| 16. | YN15V00003S015 | [1] | O-RING | KOBFOR F1 ONLY Superseded by part number: YN15V00017S063 |
| 17. | YN15V00017S017 | [3] | CHECK VALVE | KOB |
| 18. | ZR26X03200 | [1] | SNAP RING | KOBRETAINING |
| 19. | YN15V00009S019 | [1] | RING | KOBRETAINING |
| 20. | YN15V00017S020 | [1] | PISTON | KOB |
| 21. | YN15V00017S021 | [1] | BALL | KOB |
| 23. | YN15V00003S024 | [1] | SEAL | KOBPISTON |
| 24. | PR30V00010S014 | [2] | ORIFICE | KOB |
| 25. | YN15V00009S027 | [1] | OIL SEAL | KOB |
| 26. | YN15V00017S026 | [3] | SPRING | KOB |
| 27. | 2441U820S31 | [9] | SPRING | KOB |
| 28. | YN15V00017S028 | [12] | SPRING | KOB |
| 29. | YN15V00017S029 | [1] | BEARING | KOB Superseded by part number: 86557434 |
| 30. | YN15V00017S030 | [1] | BEARING | KOB |
| 31. | ZS23C16045 | [8] | CAP,Hex Socket Head, M16 x 45mm | KOBSCREW |
| 32. | YN15V00017S032 | [1] | SHIM | KOB |
| 33. | YN15V00017S033 | [1] | PIN | KOB |
| 35. | 2436U279S3 | [1] | PLUG | KOB |
| 36. | 2436U1427S25 | [10] | PLUG | KOB |
| 37. | 2436U1749S17 | [1] | PLUG | KOB |
| 38. | YN15V00017S038 | [3] | PLUG | KOB |
| 39. | 2436U1317S13 | [2] | PLUG | KOB |
| 40. | ZD12P00800 | [5] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 41. | ZD12P01100 | [4] | O-RING | KOB |
| 42. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 43. | YN15V00009S039 | [1] | O-RING | KOB |
| 44. | YN22V00013F1 | [2] | VALVE | KOBASSY, OVERLOAD RELIEF, SEE FIG. 07-030 |
| 45. | YN15V00017S045 | [1] | SPOOL | KOB |
| 46. | YN15V00017S046 | [1] | PLUG | KOB |
| 47. | 2436R874S5 | [1] | SPRING SEAT | KOB |
| 48. | 2436R874S6 | [1] | PIN | KOB |
| 49. | 2436R874S7 | [1] | SPRING | KOB |
| 50. | 2436R874S3 | [1] | FLEXIBLE JOINT | KOB |
| 51. | YN15V00017S051 | [1] | SPOOL | KOBASSY |
| 52. | YN15V00017S052 | [2] | COVER | KOB |
| 53. | YN15V00017S053 | [2] | SPRING | KOB |
| 54. | YN15V00017S054 | [2] | SEAT | KOBSPRING |
| 55. | 2436U1384S8 | [2] | VALVE | KOB |
| 56. | 2483U223S4 | [2] | SPRING | KOB |
| 57. | 2436U1139S10 | [2] | PLUG | KOB |
| 58. | YN15V00017S058 | [2] | O-RING | KOB |
| 59. | ZD12P00900 | [2] | O-RING | KOB |
| 60. | ZS23C12035 | [8] | SCREW,Hex Socket Head, M12 x 35mm | KOBCAP |
| 61. | YN15V00017S061 | [1] | BODY, FOR F2 ONLY | |
| 62. | YN15V00017S062 | [1] | RING | KOBFOR F2 & F3 ONLY |
| 63. | YN15V00017S063 | [1] | RING | KOBFOR F2 & F3 ONLY |
| . . | YN15V00017R100 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 14(9) |
| . . | YN15V00017R200 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 11(1), 22(2) |
| . . | YN15V00017R300 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 4(1), 12(1) |
| . . | YN15V00017R400 | [1] | KIT | KOBREPAIR CONSISTS OF Ref. 5(3), 7(4) |
