凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (17) - AXLE AND DIAGONAL BRACE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
262 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662988R95
|
[1] |
|
P
AXLE, (Welded assembly)
|
| . . |
137333
|
[1] |
PIN, cotter, cd-pltd., 5/16 x 3"
|
|
| 2. |
662358R94
|
[1] |
|
P
BRACE, diagonal (Welded assembly)
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, carriage, 3/8-16NC x 1"
|
| . . |
17427R1
|
[2] |
BOLT, mach., hex-hd., 7/16-14NC x 1"
|
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
hex., 7/16-14NC
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 3. |
665582R1
|
[1] |
|
P
STRAP, stiffener, diagonal brace (61- )
|
