| 1. |
351079R1
|
[6] |
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
|
IH
wheel hub Superseded by part number: 32383
|
| 2. |
518823R91
|
[1] |
WHEEL
|
IH
disk, left, w/rim, assembly
|
| 3. |
651194R1
|
[1] |
CAP
|
IH
hub
|
| 4. |
519467R91
|
[1] |
BEARING ASSY,0.8125" ID x 1.939" OD x 0.848"
|
IH
CONE, outer left wheel bearing Superseded by part number: 86613102
|
| 5. |
M32951
|
[1] |
BEARING CUP,0.75" ID x 1.938" OD x 0.78125"
|
IH
CUP, outer left wheel bearing Superseded by part number: 86539200
|
| 6. |
663003R91
|
[1] |
BEARING
|
IH
wheel, outer left, assembly Superseded by part number: M32951, 519467R91
|
| 7. |
662993R11
|
[1] |
HUB
|
IH
disk wheel, left, w/cups and bolts
|
| 8. |
54628H
|
[1] |
BEARING CUP,1.375" ID x 2.717" OD x 0.7813, 0.6250"
|
IH
CUP, inner left wheel bearing Superseded by part number: ST991
|
| 9. |
453279R91
|
[1] |
ROLLER BEARING,1.375" ID x 2.717" OD x 1.0625"
|
IH
CONE, inner left wheel bearing Superseded by part number: 36737
|
| 10. |
453278R91
|
[1] |
BEARING
|
IH
wheel, inner left, assembly Superseded by part number: ST991, 453279R91
|
| 11. |
661876R91
|
[1] |
OIL SEAL
|
IH
left wheel bearing Superseded by part number: 661875R91
|
| 12. |
662980R1
|
[1] |
SPINDLE
|
IH
wheel, left Superseded by part number: 662980R2
|
| . . |
180888
|
[1] |
SCREW, cap, hex-hd., cad-pltd., 1/2-13NC x 2-3/4"
|
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
427639
|
[1] |
SLOTTED NUT,3/4"-16, G5
|
IH
NUT, slotted, 3/4-16NF Superseded by part number: 129-290
|
| . . |
103397
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
615168R1
|
[1] |
WASHER
|
IH
plain, 25/32" ID x 1-1/2" OD x no. 11 ga. Superseded by part number: 95-81024
|
