| 1. |
662981R1
|
[1] |
SPINDLE
|
IH
wheel, right
|
| . . |
19291R1
|
[1] |
BOLT, mach., hex-hd., cad-pltd., 1/2-13NC x 2-3/4"
|
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
102649
|
[1] |
SLOTTED NUT,5/8"-18, G5
|
IH
NUT, 5/8"-18, G5 Superseded by part number: 87446
|
| . . |
103396
|
[1] |
PIN, SPLIT (COTTER),5/32" x 1"
|
IH
5/32" x 1" Superseded by part number: 120169
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
496-21066
|
[1] |
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
|
CAS
plain, 21/32" ID x 1-5/16" OD x .095 ga. Superseded by part number: 5122064
|
| 2. |
663004R91
|
[1] |
OIL SEAL
|
IH
OIL SEAL, right wheel bearing Superseded by part number: B13281
|
| 3. |
651818R91
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
CONE, inner right wheel bearing Superseded by part number: 84356153
|
| 4. |
651817R1
|
[1] |
BEARING CUP
|
IH
CUP, inner right wheel bearing Superseded by part number: 84356153
|
| 5. |
651819R91
|
[1] |
BEARING ASSY,1.2508" ID x 2.329" OD x 0.625"
|
IH
wheel, inner right, assembly Superseded by part number: 84356153, 47923369
|
| 6. |
663054R91
|
[1] |
HUB
|
IH
disk wheel, right, w/cups and bolts
|
| 7. |
651814R1
|
[1] |
BEARING CUP
|
IH
CUP, outer right wheel bearing Superseded by part number: 36725
|
| 8. |
651815R91
|
[1] |
BEARING ASSY,7.508" ID x 17.82" OD x 6"
|
IH
CONE, outer right wheel bearing Superseded by part number: 179080
|
| 8. |
651815R91GV
|
[1] |
BEARING CONE
|
MKT
Value, Cone Bearing
|
| 9. |
651816R91
|
[1] |
BEARING ASSY,7.5" ID x 17.82" OD x 6"
|
IH
BEARING, wheel, outer right, assembly Superseded by part number: 36725, 179080
|
| 10. |
651194R1
|
[1] |
CAP
|
IH
hub
|
| 11. |
662994R91
|
[1] |
WHEEL
|
IH
disk, right, w/rim, assembly
|
| 12. |
351079R1
|
[4] |
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
|
IH
wheel hub Superseded by part number: 32383
|
