| 1. |
662161R92
|
[1] |
|
P
SUPPORT, plunger Pitman (Welded assembly)
|
| . . |
102639
|
[4] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
432-1240
|
[1] |
COTTER PIN,3/16" x 2 1/2"
|
CAS
Pin, Split (Cotter), 3/16" x 2 1/2" Superseded by part number: 86523959
|
| . . |
271556
|
[4] |
WHEEL CYLINDER,Hex, 5/8" - 11 x 1 1/4", Gr 5
|
IH
SCREW, cap, hex-hd., 5/8-11NC x 1-1/4"
|
| 2. |
271284
|
[1] |
YOKE
|
NNA
lubrication, 65 degree elbow, 1/8" Superseded by part number: 219-40, 219-40, NLS
|
| 3. |
662069R1
|
[1] |
PIN
|
IH
plunger Pitman
|
| . . |
103391
|
[1] |
COTTER PIN,1/8" x 2 1/2"
|
IH
Pin, Split (Cotter), 1/8" x 2 1/2" Superseded by part number: 280987
|
| . . |
657196R1
|
[1] |
PIN
|
IH
roll, 1/4 x 2" Superseded by part number: 86624088
|
| . . |
104560
|
[1] |
WASHER, plain, 9/64" I.D. x 7/16" O.D. x no. 18 ga.
|
|
| 4. |
662165R91
|
[1] |
CRANK
|
IH
plunger (Welded assembly) Superseded by part number: 3100030R91
|
| . . |
70246D
|
[1] |
NUT
|
IH
slotted, hex., 1-1/8-12NF
|
| . . |
103389
|
[1] |
SPLIT PIN/SAFETY PIN,1/8" x 2"
|
IH
Pin, Split (Cotter), 1/8" x 2" Superseded by part number: 32-832
|
| 5. |
80710
|
[1] |
LUBE NIPPLE,1/8” – 27 Dryseal PTF
|
DUB
NIPPLE, LUBE, 1/8"-27 x .66 lg
|
| 6. |
495278R2
|
[16] |
SHIM
|
IH
Pitman bearing
|
| 7. |
495177R11
|
[1] |
NO LONGER SERVICED
|
IH
BEARING, plunger Pitman, front, assembly Superseded by part number: 495177R21
|
| . . |
664291R1
|
[2] |
BOLT,Hex, 1/2" - 13 x 2", Drilled
|
IH
SCREW, cap, hex-hd., 1/2-13NC x 2" Superseded by part number: 664573R1, 113-425
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 8. |
662208R1
|
[1] |
PITMAN
|
IH
plunger
|
| . . |
664573R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, hex., 1/2-13NC Superseded by part number: 231-4218
|
| . . |
179893
|
[2] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
IH
SCREW, cap, hex-hd., 1/2-13NC x 3" Superseded by part number: 87339
|
| 9. |
662015R1
|
[1] |
BEARING ASSY,1.256" ID x 2.375" OD x 4.1875"
|
IH
Pitman, rear
|
