凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (25) - PLUNGER PITMAN, FOR NO. 46-W BALER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
758 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662161R92
|
[1] |
|
P
SUPPORT, plunger Pitman (Welded assembly)
|
| 2. |
332040
|
[1] |
LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg
|
WIN
FITTING, lubrication, 90 degree elbow, 1/8"
|
| 3. |
664976R1
|
[2] |
BUSHING,31.8mm ID x 34.95mm OD x 44.7mm L
|
IH
BEARING, Pitman, rear
|
| 4. |
665714R91
|
[1] |
TUBE,35.75" Length
|
IH
Pitman (Welded assembly)
|
| 5. |
664967R91
|
[1] |
|
P
CRANK, plunger (Welded assembly)
|
| 6. |
664975R1
|
[2] |
BEARING LINER
|
IH
BEARING, Pitman, front
|
| 7. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 8. |
665450R1
|
[4] |
SEAL
|
IH
SEAL, plunger crank bearing Superseded by part number: 665728R1
|
| 9. |
665716R11
|
[1] |
BEARING ASSY
|
IH
Pitman, front, assembly
|
| . . |
18570R1
|
[2] |
BOLT, mach., hex., dld., 7/16-14NC x 3-3/4"
|
|
| . . |
272070
|
[2] |
TUBE
|
NNA
slotted, hex., 7/16-14NC Superseded by part number: 425-127, 425-127, NLS
|
| . . |
108636
|
[2] |
PIN
|
IH
cotter, 3/32 x 1-1/2" Superseded by part number: 432-620
|
