| 1. |
662249R11
|
[1] |
|
P
SHIELD W/DECALCOMANIA, power take-off bearing box
|
| 3. |
663104R91
|
[1] |
|
P
DRIVE, tubular (Welded assembly) (57-61)
|
| 3. |
666740R91
|
[1] |
SHAFT
|
IH
DRIVE, tubular (Welded assembly) (62- )
|
| 4. |
662589R1
|
[4] |
THRUST WASHER
|
IH
thrust (57-61)
|
| 5. |
461346R1
|
[4] |
BEARING
|
IH
nylon (57-61) Superseded by part number: T19565
|
| 5. |
464920R1
|
[4] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon (62- ) Superseded by part number: 47941, 579113
|
| 6. |
663103R91
|
[1] |
|
P
SHIELD, outer (Welded assembly) (57-61)
|
| 6. |
666738R91
|
[1] |
|
P
SHIELD, inner (Welded assembly) (62- )
|
| 7. |
102467H
|
[1] |
FITTING
|
IH
lubrication, straight, 1/4-28NF Superseded by part number: 219-20
|
| 8. |
663102R91
|
[1] |
|
P
SHIELD, inner (Welded assembly) (57-61)
|
| 8. |
666739R91
|
[1] |
|
P
SHIElD, outer (Welded assembly) (62- )
|
| 9. |
663100R91
|
[1] |
|
P
YOKE AND SHAFT (Welded assembly) (57-61)
|
| 9. |
666737R91
|
[1] |
YOKE
|
IH
AND SHAFT (Welded assembly) (62- )
|
| 10. |
569046R1
|
[3] |
CROSS
|
IH
bearing Superseded by part number: 200464C91
|
| 10. |
569047R91
|
[3] |
REPAIR KIT
|
IH
CROSS, bearing (Repair kit) Superseded by part number: 200464C91
|
| 11. |
109350
|
[3] |
FITTING, lubrication, 67-1/2 degree elbow, 1/8"
|
|
| 12. |
663101R91
|
[1] |
YOKE
|
IH
flange Superseded by part number: 663101R92
|
| 14. |
663097R91
|
[1] |
|
P
SHIELD, inner (Welded assembly) (57-61)
|
| 15. |
576433R1
|
[1] |
FORK
|
CAS
YOKE Superseded by part number: 576433R2
|
| 16. |
38904K
|
[1] |
SET SCREW,1/2" - 20 x 1-9/16"
|
IH
SCREW, set
|
| . . |
114496
|
[1] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, hex. 1/2-20NF Superseded by part number: 124934
|
| 17. |
666736R1
|
[1] |
YOKE
|
IH
(62- ) Superseded by part number: 666736R2
|
| 17. |
663095R1
|
[1] |
|
P
YOKE (57-61)
|
| . . |
577247R1
|
[1] |
LOCK PIN,3/8" x 2", Slotted
|
IH
Pin, 3/8" x 2", Slotted Superseded by part number: 438-32432
|
| 20. |
663093R91
|
[1] |
|
P
YOKE AND SHAFT (Welded assembly) (57-61)
|
| 20. |
666734R91
|
[1] |
YOKE
|
IH
AND SHAFT (Welded assembly) (62- ) Superseded by part number: 666734R92
|
| 21. |
663094R91
|
[1] |
|
P
SHIELD, outer (Welded assembly) (57-61)
|
| 23. |
569044R91
|
[12] |
BEARING ASSY
|
IH
CUP, needle, assembly Superseded by part number: 84355319
|
| 24. |
576420R1
|
[12] |
RING
|
IH
SNAP RING
|
| 25. |
455346R21
|
[1] |
PIN
|
IH
lock, assembly Superseded by part number: 237924A1
|
| 26. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X-WASHER
|
| 27. |
455346R2
|
[1] |
PIN
|
IH
lock Superseded by part number: 455346R21
|
| 28. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING Superseded by part number: 237924A1
|
| 29. |
568100R92
|
[1] |
YOKE
|
IH
w/lock pin, assembly Superseded by part number: 568100R93
|
| 30. |
662275R91
|
[1] |
|
P
SUPPORT, power take-off shaft bearing pivot bracket (Welded assembly)
|
| . . |
425-138
|
[1] |
SLOTTED NUT,1/2"-20, G8
|
CAS
NUT, SLOTTED, 1/2"-20, G8
|
| . . |
103374
|
[1] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| . . |
662086R1
|
[1] |
|
P
SCREW, cap, hex-hd. 1/2-20NF x 5-1/4"
|
| 31. |
667462R1
|
[1] |
BRACKET
|
IH
pivot, power take-off shaft bearing (63- )
|
| 31. |
662278R1
|
[1] |
|
P
BRACKET, pivot, power take-off shaft bearing (57-62)
|
| . . |
25-118
|
[1] |
NUT,1/2"-20, G5
|
CAS
hex., 1/2-20NF Superseded by part number: 425-118
|
| . . |
662084R1
|
[1] |
|
P
SCREW, cap, hex-hd., 1/2-20NF x 1-1/2"
|
| . . |
395-11053
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
CAS
plain, 17/32" I.D. x 1-1/16" O.D. x no. 13 ga.
|
| 32. |
662022R1
|
[1] |
BOX
|
IH
power take-off bearing, center (57-62)
|
| . . |
17404R1
|
[2] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 2
|
IH
mach., hex-hd., 5/16-18NC x 1/2" Superseded by part number: 88574
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 33. |
558128R91
|
[1] |
BEARING
|
IH
propeller shaft, front (57-62) Superseded by part number: 584148R91
|
| 34. |
UA20551
|
[1] |
RING
|
IH
SNAP RING, propeller shaft bearing, front (57-62)
|
| 35. |
666729R91
|
[1] |
|
P
SHAFT, main universal drive shaft, assembly (Front half)
|
| 36. |
666730R91
|
[1] |
|
P
SHAFT, main universal drive shaft, assembly (Rear half)
|
| 37. |
666735R91
|
[1] |
|
P
SHIELD, front half (Welded assembly) (62- )
|
| 38. |
613436R1
|
[1] |
CLAMP
|
IH
SNAP RING (62- ) Superseded by part number: 56760
|
| 39. |
613437R1
|
[1] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust (62- )
|
| 40. |
613439R1
|
[1] |
BRACKET
|
IH
BEARING, inner shield nylon (62- ) Superseded by part number: 754317
|
| 41. |
ST669
|
[1] |
BEARING ASSY,35mm ID
|
IH
BEARING, power take-off shaft, front (63- )
|
| 42. |
667460R1
|
[1] |
BUSHING
|
IH
power take-off center bearing (63- )
|
| . . |
17843R1
|
[1] |
BOLT, machine, hex-hd., 1/2-13NC x 5-1/2"
|
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 43. |
667461R1
|
[1] |
BRACKET
|
IH
power take-off shield (63- )
|
| . . |
17411R1
|
[4] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
machine, hex-hd., 5/16-18NC x 3/4" Superseded by part number: 179816
|
| . . |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC
|
