| 1. |
662270R1
|
[1] |
PLATE
|
IH
pressure, clutch
|
| 2. |
662046R1
|
[1] |
|
P
DISC, clutch
|
| . . |
13837R1
|
[10] |
|
P
RIVET, csk-hd., 1/4 x 5/8 x 54 degrees
|
| 3. |
662045R11
|
[1] |
FACING, CLUTCH
|
IH
w/rivets
|
| . . |
113342
|
[12] |
RIVET,Tr Hd, 3/16" x 3/8", Brass
|
IH
Superseded by part number: 113356
|
| 4. |
662044R1
|
[1] |
HOUSING, clutch lug
|
|
| 5. |
662043R91
|
[1] |
DISC
|
IH
clutch, assembly Superseded by part number: 662043R92
|
| 6. |
662269R1
|
[1] |
PLATE
|
IH
clutch, back
|
| . . |
17426R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1" Superseded by part number: 24840R1
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 7. |
M1015
|
[7] |
SPRING
|
IH
clutch
|
| . . |
15148R1
|
[7] |
BOLT, carriage, dld., 1/2-13NC x 3"
|
|
| . . |
102637
|
[7] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103374
|
[7] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| . . |
Q5111
|
[7] |
WASHER
|
IH
plain, 9/16" ID x 1-1/4" OD x no. 7 ga. Superseded by part number: 495-21056
|
| 8. |
662103R1
|
[1] |
THRUST WASHER
|
IH
thrust, flywheel
|
| 9. |
662014R11
|
[1] |
CARRIER
|
IH
over-running clutch dog, w/bushing
|
| . . |
17447R1
|
[4] |
BOLT
|
IH
mach., hex-hd., 7/16-14NC x 1-1/4"
|
| . . |
103322
|
[4] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 10. |
662241R1
|
[2] |
RATCHET
|
IH
DOG, over-running clutch Superseded by part number: 3101008R1
|
| . . |
662558R1
|
[2] |
PIN
|
IH
rod end (.496 x 1-7/8")
|
| 11. |
662078R1
|
[1] |
BUSHING
|
IH
clutch dog carrier
|
| 12. |
662120R1
|
[1] |
BUSHING
|
IH
flywheel, outer
|
| 13. |
662122R1
|
[2] |
SHEAR BOLT BUSHING,Hex, 3/4" - 16 x 1/2"
|
IH
BUSHING, shear bolt
|
| 14. |
662013R11
|
[1] |
|
P
FLYWHEEL, w/bushing
|
| 15. |
662077R1
|
[1] |
BUSHING
|
IH
flywheel, inner
|
| 16. |
662271R92
|
[1] |
|
P
HUB, flywheel (Welded assembly)
|
| . . |
425-115
|
[1] |
NUT,5/16"-24, G5
|
CAS
hex., 5/16-24NF Superseded by part number: 86629539
|
| 17. |
181347
|
[1] |
BOLT,Hex, 5/16" - 24 x 2", Gr 5
|
IH
SHEAR BOLT (No. 2 hardened cap screw) 5/16NF x 2" Superseded by part number: 60451
|
| . . |
103320
|
[1] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
664546R11
|
[1] |
SPACER
|
IH
clutch (Set of 7) (Not illustrated)
|
