纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-003) - CYLINDER HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
737 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8972221090 | [1] | CYLINDER HEAD | KOBHEAD ASM; CYL Superseded by part number: VI8973695500 |
| 1. | VI8973695500 | [1] | CYLINDER HEAD | KOBHEAD ASM; CYL |
| 2. | VI8972221171 | [1] | CYLINDER HEAD GASKET | KOBGASKET; CYL HD Superseded by part number: 288824A1 |
| 3. | VI1090701001 | [4] | BOLT | KOBBOLT; CYL HD TO BLOCK (M12X100) |
| 3. | VI1090701011 | [14] | BOLT | KOBBOLT; CYL HD TO BLOCK (M12X113) |
| 4. | VI5117210010 | [8] | VALVE GUIDE | KOBGUIDE; VLV Superseded by part number: VI1117210130 |
| 4. | VI1117210130 | [8] | VALVE GUIDE | KOBGUIDE; VLV |
| 5A. | VI8970376860 | [4] | VALVE SEAT | KOBSEAT; VLV INSERT (0D=47 INLET) Superseded by part number: VI8970376861 |
| 5B. | VI5117110280 | [4] | INSERT | KOBSEAT; VLV INSERT (0D=39 EXHAUST) |
| 6. | VI9096600340 | [4] | PLUG | KOBPLUG; PLATE |
| 7A. | VI1096000052 | [1] | CUP; SEALING, CYL HEAD (0D=45) | |
| 7B. | VI5112190150 | [2] | CUP | KOBCUP; SEALING, CYL HEAD (0D=32) Superseded by part number: VI1096000121 |
| 7C. | VI1096000160 | [7] | CUP | KOBCUP; SEALING, CYL HEAD (0D=25) |
| 7D. | VI9111291280 | [2] | CUP | KOBCUP; SEALING, CYL HEAD (0D=20) |
| 7E. | VI5096000130 | [4] | CUP | KOBCUP; SEALING, CYL HEAD (0D=12.3) Superseded by part number: VI8970363351 |
| 8. | VI9111296010 | [4] | CUP | KOBCUP; SEALING, WATER JACKET |
| 9. | VI9041108250 | [4] | STUD | KOBSTUD; INL MANIF (M8X25 L=37) Superseded by part number: VI0410108250 |
| 10. | VI1825130431 | [4] | GLOW PLUG | KOBPLUG; GLOW |
| 11. | VI5197320022 | [1] | HYD CONNECTOR | KOBCONNECTOR; GLOW PLUG |
| 12. | VI9117778050 | [1] | HANGER | KOBHANGER; ENG,RR |
| 13. | VI0280810200 | [4] | BOLT | KOBBOLT; HANGER (M10X20 FLANGE) |
| 14. | VI8941569390 | [2] | STUD | KOBSTUD; EXH MANIF (M8X75 L=87) |
| 14. | VI8941569400 | [2] | STUD | KOBSTUD; EXH MANIF (M8X60 L=72) |
| 53. | VI1093000180 | [8] | STUD | KOBSTUD; INJ NOZZLE (M8X40 L=58) |
| 54. | VI5093000650 | [3] | STUD | KOBSTUD; ROCKER ARM (M8X79 L=92) |
| 168B. | VI5117770640 | [1] | HANGER | KOBHANGER; ENG,FRT |
