纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-005) - OIL PAN AND LEVEL GAUGE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1003 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1E. | VI8972045180 | [1] | PAN | KOBPAN ASM; OIL |
| 2B. | VI8943106780 | [1] | GAUGE | KOBGAUGE; OIL LEVEL |
| 3A. | VI1096230570 | [1] | O-RING | KOBGASKET; DRAIN PLUG Superseded by part number: 87380148 |
| 4A. | VI9096620120 | [1] | DRAIN PLUG | KOBPLUG; DRAIN,OIL |
| 8B. | VI8970209320 | [1] | TUBE | KOBTUBE; GUIDE,OIL LEVEL, GAUGE |
| 9B. | VI5096230020 | [2] | O-RING | KOBGASKET; GUIDE TUBE,OIL, LEVEL GAUGE |
| 10. | VI0280808120 | [1] | BOLT; GUIDE TUBE (M8X12), FLANGE) | |
| 16. | VI8943706660 | [1] | GASKET | KOBGASKET; OIL PAN TO C/BL Superseded by part number: VI8973524030 |
| 16. | VI8973524030 | [1] | GASKET | KOBGASKET; OIL PAN TO C/BL |
| 23A. | VI0500408180 | [24] | BOLT | KOBBOLT; OIL PAN (M8X18 W/LK WASHER) |
