| 1. |
662183R91
|
[1] |
|
P
WHEEL, meter (Welded assembly) (57-61)
|
| 2. |
667450R92
|
[1] |
|
P
SUPPORT, trip sheave bearing (Welded assembly) (62- )
|
| 2. |
662180R91
|
[1] |
|
P
SUPPORT, trip sheave bearing (Welded assembly) (57-61)
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, carriage, 3/8-16NC x 1"
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
plain, 15/32" ID x 3/4 OD x no. 16 ga. Superseded by part number: 86632580
|
| 4. |
662441R11
|
[1] |
SHAFT
|
IH
trip roller (Welded assembly) (57-61) Superseded by part number: 3100388R11
|
| . . |
425-1110
|
[1] |
NUT,5/8"-18, G5
|
CAS
Superseded by part number: 408
|
| . . |
17053R1
|
[1] |
LOCK PIN,Sl Spring, 1/4" x 1 3/8"
|
IH
PIN, 1/4" x 1 3/8", Slotted Superseded by part number: 87524
|
| . . |
1033325
|
[1] |
HUB ASSY.
|
CON
WASHER, lock, 5/8"
|
| . . |
615226R1
|
[1] |
WASHER
|
IH
plain, 1-1/32" ID x 1-1/2" OD x no. 22 ga. (As required) Superseded by part number: 86624168
|
| 5. |
662442R1
|
[2] |
PULLEY
|
IH
ROLLER, trip
|
| 6. |
665033R1
|
[1] |
SPACER
|
IH
trip roller
|
| 7. |
662031R1
|
[1] |
COLLAR
|
IH
set, trip
|
| . . |
114503
|
[1] |
JAM NUT,Jam, 3/8"-16, G5
|
IH
Superseded by part number: 329-146
|
| . . |
102897
|
[1] |
SET SCREW,Sq Hd, 3/8"-16 x 1 1/4"
|
IH
Sq Hd, 3/8"-16 x 1 1/4" (Cup Pt) Superseded by part number: 87532
|
| 8. |
664779R92
|
[1] |
|
P
ROD, trip (Welded assembly) (No. 46-W baler)
|
| 8. |
662279R93
|
[1] |
ROD
|
IH
trip (Welded assembly) (No. 46-T baler) Superseded by part number: 662279R94
|
| . . |
18265R1
|
[1] |
LOCK PIN,3/8" x 1 1/4", Slotted
|
IH
Pin, 3/8" x 1 1/4", Slotted Superseded by part number: 38-32420
|
| 9. |
663163R21
|
[1] |
ARM
|
IH
trip, w/stud and roller (No. 46-W baler)
|
| 9. |
662018R11
|
[1] |
LEVER
|
IH
ARM, trip, w/stud and roller (No. 46-T baler)
|
| . . |
103373
|
[1] |
COTTER PIN,3/32" x 3/4"
|
IH
Pin, Split (Cotter), 3/32" x 3/4" Superseded by part number: 32-612
|
| 10. |
662020R1
|
[1] |
STUD
|
IH
trip arm roller
|
| . . |
28035K
|
[1] |
WASHER
|
IH
plain, 13/32" ID x 1" OD x no. 22 ga. Superseded by part number: 495-81136
|
| 11. |
662019R1
|
[1] |
ROLLER,28.57mm OD x 12.7mm L
|
IH
trip arm
|
| 12. |
664806R1
|
[1] |
|
P
ANCHOR, trip spring (No. 46-W baler)
|
| 12. |
662102R1
|
[1] |
|
P
ANCHOR, trip spring (No. 46-T baler)
|
| 13. |
13985V
|
[1] |
SPRING
|
IH
trip
|
| 14. |
664778R1
|
[1] |
PIN
|
IH
STUD, trip arm (No. 46-W Baler)
|
| . . |
576517R1
|
[1] |
LOCK PIN,1/4" x 1 1/2", Slotted
|
IH
Pin, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
|
| . . |
Q3501
|
[1] |
WASHER
|
IH
plain, 25/32" ID x 1-1/4" OD x no. 16 ga. Superseded by part number: 95-81056
|
| 14. |
662072R1
|
[1] |
NO LONGER SERVICED
|
IH
STUD, trip arm (No. 46-T baler) Superseded by part number: 662072R2
|
| . . |
103385
|
[1] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| 15. |
667452R91
|
[1] |
|
P
WHEEL, meter (Welded assembly) (62- )
|
| . . |
17475R1
|
[1] |
BOLT, mach., hex-hd. 5/8-11NC x 1-1/2"
|
|
| . . |
21868V
|
[2] |
WASHER
|
IH
plain, 29/32" ID x 1-1/2" OD x no. 16 ga. Superseded by part number: 86624166
|
| . . |
578274R1
|
[1] |
WASHER
|
IH
plain, 21-32" ID x 1" OD x no. 11 ga. Superseded by part number: 87613215
|
| . . |
667778R1
|
[2] |
BUSHING
|
IH
trip sheave support
|
