| 1. |
662214R1
|
[1] |
|
P
SUPPORT, packer bearing
|
| . . |
14995R1
|
[3] |
BOLT
|
IH
carriage, 3/8-16NC X 3/4" Superseded by part number: 19284R1
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
11463P
|
[2] |
|
P
DISK, packer drive bearing
|
| . . |
17575R1
|
[4] |
BOLT, mach., hex-hd., 7/16-14NC x 2-1/2"
|
|
| . . |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
hex., 7/16-14NC
|
| . . |
103322
|
[4] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 3. |
656851R1
|
[1] |
|
P
BEARING, packer drive
|
| . . |
551769R1
|
[2] |
WASHER
|
IH
plain, 1-13/32" ID x 2" OD x no. 16 ga. Superseded by part number: 495-81213
|
| 4. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, lubrication, self tapping, 1/4"
|
| 5. |
662186R93
|
[1] |
|
P
SHEET, feed opening, top (Welded assembly)
|
| . . |
15543R1
|
[2] |
BOLT
|
IH
plow, 3/8-16NC x 3/4"
|
| . . |
15551R1
|
[2] |
BOLT,3/8"-16 x 1", G2, Full Thd
|
IH
plow, 3/8-16NC x 1" Superseded by part number: 419-3616
|
| 6. |
662121R1
|
[1] |
|
P
STRAP, tie, feed opening top sheet
|
| 7. |
662038R1
|
[1] |
DEFLECTOR
|
IH
feed opening
|
| . . |
86508749
|
[2] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
|
GI
BOLT, carriage, 3/8-16NC x 1-1/4"
|
| 8. |
662040R1
|
[1] |
DEFLECTOR
|
IH
feed opening, rear
|
| . . |
80280503
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, carriage, 3/8-16NC x 1"
|
| 9. |
662039R1
|
[1] |
|
P
RUNNER, feed opening top sheet
|
