纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-017) - TURBOCHARGER SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
966 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8972234280 | [1] | TURBOCHARGER | KOBTURBOCHARGER ASM, SEE FIG 08-018 |
| 2. | VI8943690230 | [1] | GASKET | KOBGASKET; TURBOCHARGER TO EXH MANIF |
| 12. | VI8944762820 | [3] | STUD | KOBSTUD; TURBOCHARGER (M8X25 L=36) Superseded by part number: VI8973780620 |
| 77. | VI0287810250 | [2] | BOLT | KOBBOLT; INL DUCT (M10X25 FLANGE), TCY ONLY |
| 77. | VI0280806120 | [1] | BOLT | KOBBOLT; INL DUCT (M6X12 FLANGE) |
| 77. | VI0280808160 | [2] | BOLT; INL DUCT (M8X16 FLANGE) | |
| 133A. | VI8972221210 | [1] | PIPE | KOBPIPE; OIL DRAIN, TURBOCHARGER |
| 134A. | VI8943690220 | [1] | PACKING | KOBGASKET; OIL PIPE, TURBOCHARGER DRAIN |
| 134B. | VI8943706630 | [1] | GASKET | KOBGASKET; OIL PIPE, TURBOCHARGER DRAIN |
| 148. | VI1093607820 | [1] | HOSE | KOBHOSE; TURBOCHARGER, INL |
| 150. | VI8970614011 | [4] | NUT | KOBNUT; INL DUCT |
| 332. | VI8972410420 | [4] | DUCT; AIR, TURBOCHARGER, TCY ONLY | |
| 388. | VI8943690210 | [1] | GASKET | KOBGASKET; EXH PIPE |
| 401A. | VI0280806160 | [2] | BOLT | KOBBOLT; OIL PIPE, TURBO (M6X16 FLANGE) Superseded by part number: VI0280506160 |
| 461. | VI9041108220 | [2] | STUD | KOBSTUD; OIL PIPE, TURBO (M8X22 L=34) |
| 462. | VI0911501080 | [2] | NUT | KOBNUT; OIL PIPE, TURBO Superseded by part number: VI0911802080 |
