| 1. |
665092R1
|
[1] |
|
P
BRACKET, wire can support angle, left rear
|
| . . |
17426R1
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1" Superseded by part number: 24840R1
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
665091R1
|
[1] |
|
P
ANGLE, wire can, left
|
| 3. |
11833PB
|
[1] |
GUIDE
|
IH
wire Superseded by part number: 1344948C1
|
| 4. |
496158R2
|
[1] |
BRACKET
|
IH
wire guide
|
| . . |
14994R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2 Superseded by part number: 434-512
|
| . . |
9635082
|
[1] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC
|
| . . |
103320
|
[1] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 5. |
664801R1
|
[2] |
|
P
BRACE, wire can support
|
| . . |
17412R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 3/4" Superseded by part number: 86500692
|
| . . |
17427R1
|
[2] |
BOLT, mach., hex-hd., 7/16-14NC x 1"
|
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
hex., 7/16-14NC
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 6. |
665093R1
|
[1] |
|
P
BRACKET, wire can support angle, left front
|
| 7. |
664789R1
|
[1] |
|
P
BRACKET, wire can support angle, right rear
|
| 8. |
664797R1
|
[1] |
|
P
ANGLE, wire cank, right
|
| 9. |
664788R1
|
[1] |
|
P
BRACKET, wire can support angle, right front
|
