| 1. |
662176R91
|
[1] |
AUGER
|
IH
(Welded assembly) Superseded by part number: 754622R91
|
| . . |
Q3648
|
[1] |
PIPE
|
P
plain, 29/32" ID x 2" OD x no. 16 ga. Superseded by part number: NLS
|
| 2. |
495290R1
|
[4] |
BUSHING
|
IH
auger core and drive shaft
|
| 3. |
662172R92
|
[1] |
|
P
RELIEF AND SUPPORT, auger (Welded assembly)
|
| 4. |
662213R1
|
[1] |
V-BELT,0.88" W
|
IH
Auger drive 0.88" W Superseded by part number: 86517914
|
| 5. |
662258R2
|
[1] |
|
P
SHIELD, auger drive
|
| . . |
19419R1
|
[4] |
BOLT, mach., hex-hd., 5/16-18NC x 1/2" (Cd-pltd.)
|
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 6. |
495480R1
|
[4] |
PULLEY
|
IH
SHEAVE, auger drive
|
| 7. |
495170R2
|
[2] |
HUB CAP
|
IH
HUB, v-sheave
|
| . . |
17470R1
|
[8] |
BOLT
|
IH
mach., hex-hd., 5/16-18NC x 1-1/2" Superseded by part number: 179822
|
| . . |
9635082
|
[8] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC
|
| . . |
103384
|
[2] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| . . |
616253R1
|
[2] |
LOCK PIN,5/16" x 1 5/8", Slotted
|
IH
Pin, 5/16" x 1 5/8", Slotted Superseded by part number: 70921559
|
| . . |
Q397
|
[40] |
WASHER
|
IH
plain, 11/32" ID x 3/4" OD x no. 16 ga. Superseded by part number: 95-81069
|
| 8. |
Q2780
|
[4] |
WASHER
|
IH
plain, 29/32" ID x 1-11/32" OD x no. 20 ga.
|
| 9. |
664777R1
|
[1] |
|
P
SHAFT, auger drive (No. 46-W baler)
|
| 9. |
662287R1
|
[1] |
SHAFT
|
IH
auger drive (No. 46-T baler) Superseded by part number: 754624R1
|
| . . |
551659R1
|
[1] |
WASHER
|
IH
plain, 29/32" ID x 1-1/2" OD x no. 22 ga.
|
| 10. |
664766R1
|
[1] |
|
P
PINION, auger drive (13 teeth) (No. 46-W baler)
|
| . . |
112139
|
[1] |
WOODRUFF KEY,#A, 1/4" x 7/8"
|
IH
KEY, Woodruff, 1/4 x 7/8" Superseded by part number: 280934
|
| 10. |
495162R4
|
[1] |
GEAR
|
IH
PINION, auger drive (13 teeth) (No. 46-T baler) Superseded by part number: 3100446R1
|
| . . |
142534
|
[1] |
GROOVED PIN,1.126" ID
|
IH
Pin, Grooved, 5/16" x 1 3/4", Type A Superseded by part number: NLS
|
| . . |
VC649
|
[1] |
WASHER
|
IH
plain, 29/32" ID x 1-3/4 OD x no. 16 ga.
|
| . . |
454331R1
|
[1] |
SNAP RING,#87, Ext
|
IH
Auger drive pinion (No. 46-W baler) #87, Ext Superseded by part number: 137286
|
| . . |
662628R92
|
[1] |
|
P
KIT, decalcomania (No. 46-T baler), Composed of DECALCOMANIAS
|
| . . |
2751050R1
|
[2] |
PRODUCT GRAPHIC
|
IH
MCCORMICK INTERNATIONAL, (1) on end sheet, (1) on left front bale chamber side DECALCOMANIAS Superseded by part number: 547495R92
|
| . . |
2750221R1
|
[2] |
|
P
IH, (1) on end sheet, (1) on left bale chamber side DECLACOMANIAS
|
| . . |
1001422R1
|
[2] |
|
P
IH, (1) on packer drive shaft bearing support, (1) on twine chest cover DECALCOMANIAS
|
| . . |
2751051R1
|
[1] |
PRODUCT GRAPHIC
|
IH
MCCORMICK INTERNATIONAL, (1) on twine chest cover DECALCOMANIAS Superseded by part number: 547495R92
|
| . . |
666679R92
|
[1] |
|
P
KIT, decalcomania (No. 46-W baler), Composed of DECALCOMANIAS
|
