凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (71) - BALE CHUTE ATTACHMENT, SPECIAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
502 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
662427R91
|
[1] |
BALE CHUTE ATTACHMENT, Consists of all the parts listed below
|
|
| 1. |
662325R91
|
[2] |
CHAIN (AG)
|
IH
CHAIN, bale chute
|
| . . |
15007R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2 Superseded by part number: 598803R1, 411-516
|
| . . |
657803R1
|
[2] |
|
P
NUT, wing, 5/16-18NC
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
Q397
|
[2] |
WASHER
|
IH
plain, 11/32" ID x 3/4" OD x no. 16 ga. Superseded by part number: 95-81069
|
| 2. |
662133R1
|
[4] |
SPRING, LEAF
|
IH
STRAP, hinge, bale chamber extension
|
| . . |
14995R1
|
[8] |
BOLT
|
IH
carriage, 3/8-16NC x 3/4" Superseded by part number: 19284R1
|
| . . |
102635
|
[8] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103384
|
[2] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| . . |
PO15464
|
[2] |
HEADED PIN,3/8" x 4"
|
IH
PIN, std-hd., 3/8 x 4" Superseded by part number: 631252R1
|
| . . |
103321
|
[8] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
plain, 13/32" ID x 3/4 OD x no. 16 ga. Superseded by part number: 86632580
|
| 3. |
662254R1
|
[1] |
|
P
CHUTE, bale
|
