凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (72) - PLUNGER CRANK SHIELD, SPECIAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
792 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
662424R91
|
[1] |
PLUNGER CRANK SHIELD, Consists of all parts listed below
|
|
| 1. |
662324R1
|
[1] |
|
P
HINGE, plunger crank shield
|
| . . |
Q1504
|
[3] |
WASHER
|
IH
plain, 13/32" ID x 7/8" OD x no. 16 ga. Superseded by part number: 495-21044
|
| 2. |
662323R1
|
[1] |
|
P
ROD, hinge
|
| 3. |
662250R91
|
[1] |
|
P
SHIELD, plunger crank (Welded assembly)
|
| . . |
662351R91
|
[1] |
|
P
PLUNGER CRANK SHIELD (For use with Wisconsin engine attachment) Consists of all the parts listed below
|
