凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (73) - JACKSTAND ATTACHMENT, SPECIAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
483 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
662425R91
|
[1] |
JACKSTAND ATTACHMENT, Consists of all the parts listed below
|
|
| 1. |
662326R1
|
[1] |
|
P
HANDLE, jackstand
|
| . . |
103384
|
[1] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| . . |
Q1504
|
[1] |
WASHER
|
IH
plain, 13/32" ID x 7/8 OD x no. 16 ga. Superseded by part number: 495-21044
|
| 2. |
662328R91
|
[1] |
|
P
SCREW, jackstem (Welded assembly)
|
| . . |
103397
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341
|
| . . |
656631R1
|
[1] |
PIN
|
IH
roll, 3/16 x 1-1/64" Superseded by part number: 70922945
|
| . . |
Q3481
|
[1] |
WASHER
|
IH
plain, 1-1/32" ID x 1-1/2" OD x no. 16 ga. Superseded by part number: 86624169
|
| 3. |
80710
|
[2] |
LUBE NIPPLE,1/8” – 27 Dryseal PTF
|
DUB
NIPPLE, LUBE, 1/8"-27 x .66 lg
|
| 4. |
662052R1
|
[1] |
|
P
BLOCK, pivot, jackstand
|
| 5. |
662327R1
|
[1] |
ROD
|
IH
PIN, lock, jackstand
|
| 6. |
T249
|
[1] |
SPRING
|
IH
jackstand pivot pin Superseded by part number: T249-1
|
| 7. |
667552R1
|
[1] |
|
P
JACKSTEM, lower
|
