| 1. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 2. |
659489R1
|
[1] |
|
P
CAP, hub, idler pulley
|
| . . |
17425R1
|
[3] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
mach., hex-hd., 5/16-18NC x 1" Superseded by part number: 179818
|
| . . |
103320
|
[3] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 3. |
659494R1
|
[1] |
|
P
GASKET, idler pulley hub cap
|
| 4. |
659514R1
|
[1] |
|
P
WASHER, thrust, idler
|
| . . |
659517R1
|
[2] |
|
P
BOLT, special, 1/4-20NC x 3/4"
|
| . . |
103319
|
[2] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 5. |
511752R91
|
[2] |
BEARING, ROLLER
|
IH
BEARING, idler pulley
|
| 6. |
659506R1
|
[1] |
SPACER
|
IH
idler pulley bearing Superseded by part number: 151478C1
|
| 7. |
451894R1
|
[1] |
|
P
RACE, outer, split sleeve
|
| 8. |
659490R1
|
[1] |
|
P
PULLEY, idler, engine
|
| 9. |
615237R1
|
[1] |
WASHER
|
IH
plain, 1-1/16" ID x 2" OD x no. 16 ga. Superseded by part number: 609836R1
|
| 10. |
7049H
|
[1] |
|
P
WASHER, felt, 1" ID x 2" OD x 5/16" thick
|
| 11. |
659493R1
|
[1] |
|
P
CUP, retainer, idler
|
| 12. |
663935R21
|
[1] |
|
P
SUPPORT, w/bushing, engine
|
| . . |
17498R1
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 2
|
CAS
mach., hex-hd., 1/2-13NC x 1-3/4"
|
| . . |
664646R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, hex., 7/16-14NC (Special) Superseded by part number: 280980
|
| . . |
179867
|
[3] |
BOLT,Hex, 7/16" - 14 x 2 1/4", Gr 5
|
IH
SCREW, cap, hex-hd., 7/16-14NC x 2-1/4" Superseded by part number: 86505984
|
| . . |
179868
|
[1] |
BOLT,Hex, 7/16" - 14 x 2 1/2", Gr 5
|
IH
SCREW, cap, hex-hd., 7/16-14NC x 2-1/2" Superseded by part number: 24853R1
|
| . . |
103322
|
[4] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
103323
|
[4] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
PO105341/2
|
[1] |
WASHER, plain, 15/32 x 1-1/2" x no. 11 ga.
|
|
| . . |
42274H
|
[1] |
SPACER
|
IH
WASHER, plain, 15/32 x 7/8 x no. 7 ga. Superseded by part number: 62036R1
|
| 13. |
664605R1
|
[1] |
|
P
REINFORCEMENT, bale chamber
|
| . . |
15040R1
|
[1] |
BOLT,Sht Sq Nk, 7/16" - 14 x 1 1/2"
|
IH
carriage, 7/16-14NC x 1-1/2" Superseded by part number: 111-421
|
| . . |
17446R1
|
[1] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1-1/4" Superseded by part number: 88011
|
| . . |
17447R1
|
[1] |
BOLT
|
IH
mach., hex-hd., 7/16-14NC x 1-1/4"
|
| . . |
102635
|
[1] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[1] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 14. |
662338R1
|
[2] |
SPACER
|
IH
engine base
|
| 15. |
86534426
|
[1] |
ELBOW
|
CAS
1/8 x 90 degrees Superseded by part number: CAS86534426, CAS86534426, NNA86534426
|
| 16. |
222-762
|
[1] |
ELBOW,90 Degree, 7/16"-20, 45 Degree Fl x 1/8" NPT
|
CAS
|
| 17. |
659495R1
|
[1] |
|
P
STOP, engine idler lever
|
| . . |
17426R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1" Superseded by part number: 24840R1
|
| 18. |
662340R1
|
[1] |
GRIP
|
IH
idler strap
|
| 19. |
27385D
|
[1] |
|
P
CLIP, loom (For 3/8" bolt)
|
| 19. |
52728D
|
[1] |
|
P
CUSHION, fuel line
|
| 20. |
27386D
|
[1] |
|
P
CLIP, loom (For 1/2" bolt)
|
| . . |
179864
|
[1] |
BOLT,Hex, 7/16" - 14 x 1 3/4", Gr 5
|
IH
SCREW, cap, hex-hd., 7/16-14NC x 1-3/4" Superseded by part number: 13-728
|
| 21. |
662346R1
|
[1] |
|
P
SUPPORT, fuel tank
|
| 23. |
663038R11
|
[2] |
|
P
STRAP, fuel tank, w/webbing
|
| . . |
17496R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 3/4"
|
IH
mach., hex-hd., 3/8-16NC x 1-3/4"
|
| 24. |
662339R1
|
[1] |
BELT,3.50" W x 97.75" L
|
IH
Drive 3.50" W x 97.75" L
|
| 25. |
662053R11
|
[1] |
|
P
PULLEY, engine, w/set screw
|
| . . |
657205R1
|
[1] |
|
P
KEY 3/8" Sq x 3 1/4", Par
|
| . . |
102595
|
[2] |
SCREW, set, hex-socket-hd., cup-pt., 3/8-16NC x 3/4"
|
|
| 26. |
661249R1
|
[1] |
|
P
WHEEL, crank
|
| . . |
179838R1
|
[3] |
|
P
SCREW, cap, hex-hd., 3/8-16NC x 7/8"
|
| . . |
Q3830
|
[3] |
WASHER
|
IH
plain, 13/32" ID x 1-1/2" OD x no. 11 ga. Superseded by part number: 477589R1
|
| 27. |
662329R92
|
[1] |
|
P
BRACKET, engine idler (Welded assembly)
|
| . . |
103387
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
IH
Pin, Split (Cotter), 1/8" x 1 1/2" Superseded by part number: 80708
|
| . . |
Q1557
|
[3] |
WASHER
|
IH
plain, 29/32" ID x 1-3/8" OD x no. 10 ga.
|
| . . |
615193R1
|
[2] |
WASHER
|
IH
plain, 29/32" ID x 1-3/8" OD x no. 16 ga.
|
| . . |
667942R1
|
[2] |
|
P
BUSHING, engine idler support
|
| . . |
110675
|
[1] |
CAP,3/8" NPT
|
CAS
pipe, 3/8" (Not illustrated) Superseded by part number: 221-1524
|
| . . |
12989R1
|
[1] |
|
P
NIPPLE, pipe, 3/8 x 7-1/2" (Not illustrated) Nipple, 3/8" NPT x 7 1/2"
|
| . . |
662982R91
|
[1] |
WISCONSIN ENGINE - MANUAL STARTER (A)
|
|
| . . |
662983R91
|
[1] |
WISCONSIN ENGINE - STARTER AND GENERATOR (Self-contained unit) (B)
|
|
| . . |
662984R91
|
[1] |
WISCONSIN ENGINE - WITH 6-VOLT STARTER (For tractor electrical system - cable transmission) (C)
|
|
| . . |
662985R91
|
[1] |
WISCONSIN ENGINE - WITH 12-VOLT STARTER (For tractor electrical system - cable transmission) (C)
|
|
