纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-027[02]) - GENERATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
588 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI1812005303 | [1] | GENERATOR | KOBGENERATOR ASM (24V-50A MITSUBISHI) Superseded by part number: VI1812005306 |
| 1. | VI1812143670 | [1] | COVER ASM; RR,GEN | |
| 2. | VI1812111020 | [1] | ROTOR; GEN | |
| 3B. | VI1812297690 | [1] | BEARING; ROTOR,GEN | |
| 3A. | VI1812297700 | [1] | BEARING; ROTOR,GEN | |
| 4C. | VI1812298390 | [1] | TERMINAL; BRUSH,GEN | |
| 6. | VI1812600170 | [1] | REGULATOR ASM; VOLTAGE, GEN | |
| 10D. | VI1812298330 | [1] | RECTIFIER; GEN | |
| 16. | VI1812297710 | [1] | TERMINAL ASM; RECTIFIER, GEN | |
| 17. | VI1812131010 | [1] | COVER ASM; FRT,GEN | |
| 19. | VI1812221301 | [1] | PULLEY; GEN | |
| 22. | VI1812111290 | [1] | STATOR; GEN | |
| 23. | VI1812120160 | [1] | COIL; ROTOR GEN | |
| 27B. | VI1812297720 | [1] | NUT; RECTIFIER, GEN | |
| 36. | VI1812297680 | [4] | SCREW; FRT COVER | |
| 43A. | VI1812294770 | [3] | SCREW | KOBSCREW; RR END COVER |
| 43B. | VI1812298320 | [1] | SCREW; RR END COVER | |
| 43A. | VI1812297740 | [1] | SCREW; RR END COVER | |
| 43C. | VI1812297730 | [1] | SCREW; RR END COVER | |
| 69. | VI1812298360 | [1] | CLIP; WIRE, GEN | |
| 86. | VI8971781340 | [1] | NUT SET; PULLEY, GEN | |
| 127. | VI1812297670 | [1] | BOLT SET; GEN | |
