凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (85) - FLOATING PICKUP WHEEL ATTACHMENT, SPECIAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
219 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
662423R92
|
[1] |
FLOATING PICKUP WHEEL (Machine attachment), Consists of all the parts listed below
|
|
| 1. |
659918R1
|
[2] |
BUSHING
|
IH
wheel
|
| 2. |
659917R91
|
[1] |
|
P
WHEEL, pickup
|
| 3. |
667723R91
|
[1] |
|
P
BRACKET, pickup wheel (Welded assembly)
|
| . . |
17427R1
|
[2] |
BOLT, mach., hex-hd., 7/16-14NC x 1"
|
|
| . . |
432-1220
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Pin, Split (Cotter), 3/16" x 1 1/4" Superseded by part number: 87398
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
W6652
|
[1] |
WASHER
|
IH
plain, 15/32" ID x 1" OD x no. 16 ga. Superseded by part number: 495-81158
|
| . . |
Q3501
|
[2] |
WASHER
|
IH
plain, 25/32" ID x 1-1/4" OD x no. 16 ga. Superseded by part number: 95-81056
|
