659423R91
|
[1] |
PUMP, assembly, Consists of all the parts listed below
|
|
| 1. |
222-935
|
[1] |
ELBOW
|
CAS
tube, flared 90 degrees
|
| 2. |
16009R1
|
[1] |
BALL
|
IH
steel, 9/32" Superseded by part number: 17009R1
|
| 3. |
659535R1
|
[1] |
|
P
ADAPTER, pressure relief valve
|
| 4. |
659545R1
|
[1] |
|
P
SPRING, pressure relief valve
|
| 5. |
659538R1
|
[1] |
|
P
SHIM, adjusting, pressure (Order as required)
|
| 6. |
143997
|
[3] |
PLUG
|
IH
pipe, hdls., 1/4-NPTF Superseded by part number: 217-433
|
| 7. |
659531R1
|
[1] |
|
P
SPRING, discharge
|
| 8. |
659539R1
|
[2] |
|
P
POPPET, spring
|
| 9. |
659561R1
|
[1] |
|
P
WASHER, back-up
|
| 10. |
350667R1
|
[1] |
O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro
|
IH
3/32 x 11/16" Superseded by part number: 75285739
|
| 11. |
659544R1
|
[1] |
|
P
SPRING, intake
|
| 13. |
659534R1
|
[1] |
|
P
FOOT, plunger
|
| 14. |
17088R1
|
[1] |
|
P
PIN, roll, 1/8 x 1/2"
|
| 15. |
659537R1
|
[2] |
|
P
RETAINER, spring
|
| 16. |
659543R1
|
[1] |
|
P
SPRING, metering rod
|
| 17. |
659536R1
|
[1] |
|
P
TUBE, stop
|
| 18. |
659546R1
|
[1] |
|
P
SPRING, return, piston
|
| 19. |
659542R1
|
[1] |
WASHER, retainer, piston spring
|
|
| 20. |
659528R91
|
[1] |
|
P
PISTON AND SLEEVE, assembly
|
| 21. |
659541R1
|
[1] |
|
P
PLUNGER
|
| 22. |
269174R1
|
[1] |
SNAP RING,#62, Ext
|
IH
Ring, Snap, , plunger #62, Ext Superseded by part number: 515259
|
| 23. |
454331R1
|
[1] |
SNAP RING,#87, Ext
|
IH
Piston #87, Ext Superseded by part number: 137286
|
| 24. |
659525R91
|
[1] |
ARM, rocker, w/rollers, assembly
|
|
| 25. |
659562R1
|
[1] |
|
P
RING, quad
|
| 26. |
659532R1
|
[2] |
|
P
SPRING, retainer
|
| 27. |
659540R1
|
[1] |
|
P
PIN, piston and sleeve
|
| 28. |
659547R1
|
[1] |
|
P
ROD, metering
|
| 29. |
659526R1
|
[2] |
|
P
ROLLER, rocker arm
|
| 30. |
17235R1
|
[3] |
LOCK PIN,3/8" x 15/16", Slotted
|
IH
Pin, 3/8" x 15/16", Slotted Superseded by part number: 138-233
|
| 31. |
659533R1
|
[1] |
|
P
BUSHING, pump cover
|
| 32. |
659716R1
|
[1] |
PLUG, hex-hd., 7/8-14NF
|
|
| 33. |
659527R91
|
[1] |
|
P
STRAINER, pump
|
| 34. |
659549R1
|
[1] |
COVER, pump
|
|
| . . |
179817
|
[4] |
BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd
|
IH
Superseded by part number: 280345
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 35. |
659566R1
|
[1] |
|
P
BREATHER, pump
|
| 36. |
659548R1
|
[1] |
|
P
GASKET, cover
|
| 37. |
659550R1
|
[1] |
BODY, valve
|
|
| . . |
15266R1
|
[2] |
BOLT, carriage, 3/8-16NC x 5"
|
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103397
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 38. |
103878
|
[2] |
PLUG
|
IH
pipe, sq-hd., 1/4-NPTF Superseded by part number: 444576
|
