凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (88[B]) - FLYWHEEL AND BELT SHIELD, SPECIAL, FOR ENGINE DRIVE BALERS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
858 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
663661R92
|
[1] |
FLYWHEEL AND BELT SHIELD ATTACHMENT (For engine drive balers)
|
|
| 1. |
11931P
|
[1] |
|
P
SHIELD, belt
|
| . . |
14995R1
|
[2] |
BOLT
|
IH
mach., hex-hd., 3/8-16NC x 3/4" Superseded by part number: 19284R1
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
663663R1
|
[2] |
|
P
BRACKET, shield support
|
| . . |
17426R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 1" Superseded by part number: 24840R1
|
| 3. |
663662R2
|
[1] |
|
P
SHIELD, flywheel
|
| . . |
17412R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
mach., hex-hd., 3/8-16NC x 3/4" Superseded by part number: 86500692
|
