沃尔沃零件查询MD2010-C; MD2010-D; MD2020-C; MD2020-D; MD2030-C; MD2030-D; MD2040-C; MD2040-D; 120S-D; 120S-ECooling SystemHeat ExchangerEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
667 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3581924
|
[1] |
Heat exchanger housi
|
|
| 1. |
|
|
|
|
| 2. |
3581929
|
[1] |
Heat exchanger
|
|
| 3. |
861920
|
[2] |
Cover
|
|
| 4. |
961672
|
[2] |
Hose clamp
|
|
| 5. |
961673
|
[2] |
Hose clamp
|
|
| 6. |
3580328
|
[1] |
Tube
|
|
| 7. |
861926
|
[1] |
Rubber hose
|
Sea water pump-heat exchanger.
|
| 8. |
961667
|
[1] |
Hose clamp
|
|
| 9. |
853548
|
[1] |
Hose clamp
|
|
| 10. |
861927
|
[1] |
Rubber hose
|
Heat exchanger-water pump.
|
| 11. |
961667
|
[1] |
Hose clamp
|
|
| 12. |
861911
|
[1] |
Thermostat
|
|
| 13. |
861910
|
[1] |
Spring
|
|
| 14. |
|
|
|
|
| 15. |
961662
|
[1] |
Hose clamp
|
|
| 16. |
861379
|
[1] |
Decal
|
|
| 17. |
3581770
|
[1] |
Filler cap
|
|
