| 1. |
667446R1
|
[1] |
|
P
BEARING, twister shaft L.
|
| . . |
17446R1
|
[2] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach. 3/8 x 1-1/4 Superseded by part number: 88011
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
664773R1
|
[1] |
SHAFT
|
IH
wire twister
|
| . . |
551769R1
|
[8] |
WASHER
|
IH
1-13/32 x 2 x 16 ga. Superseded by part number: 495-81213
|
| . . |
Q275
|
[1] |
WASHER
|
IH
1-13/32 x 2 x 20 ga (or as required) Superseded by part number: 495-81213
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
SPLIT (COTTER), 3/16" x 2"
|
| 3. |
657783R91
|
[2] |
TWISTER
|
IH
HOOK, wire twister asm.
|
| . . |
19336R1
|
[2] |
LOCK PIN,1/8" x 11/16", Slotted
|
IH
Pin, 1/8" x 11/16", Slotted Superseded by part number: 38-1811
|
| . . |
17498R1
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 2
|
CAS
mach. 1/2 x 1-3/4
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
16038R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 11 ga. Superseded by part number: 86624146
|
| 4. |
656913R2
|
[2] |
PINION
|
IH
twister
|
| . . |
657196R1
|
[4] |
PIN
|
IH
roll, 1/4 x 2 Superseded by part number: 86624088
|
| 5. |
656895R22
|
[1] |
TWISTER
|
IH
ASSY, LH
|
| 5. |
656895R2
|
[1] |
TWISTER
|
IH
FRAME, wire twister LH Superseded by part number: 656895R22
|
| 6. |
657163R1
|
[6] |
SHIM
|
IH
keeper blade .010
|
| 7. |
656947R1
|
[2] |
BLOCK DRIVER
|
IH
PINION, wire clamp & cutter helical
|
| 8. |
657128R1
|
[2] |
SPACER
|
IH
wire knife
|
| 9. |
657164R1
|
[16] |
SHIM
|
IH
wire knife & keeper blade
|
| 10. |
656948R1
|
[2] |
SHAFT
|
IH
wire holder
|
| . . |
Q5035
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga. Superseded by part number: 495-81254
|
| . . |
551658R1
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 22 ga. (or as req.) Superseded by part number: 87613196
|
| . . |
25-118
|
[2] |
NUT,1/2"-20, G5
|
CAS
1/2 NF Superseded by part number: 425-118
|
| . . |
114496
|
[2] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, jam 1/2 NF Superseded by part number: 124934
|
| 11. |
656893R1
|
[2] |
HUB
|
IH
wire holder disc
|
| 12. |
657123R2
|
[2] |
HOLDER
|
IH
DISC, wire holder
|
| 13. |
657124R2
|
[2] |
SPACER
|
IH
wire holder disc
|
| 14. |
657127R1
|
[2] |
NO LONGER SERVICED
|
IH
BLADE, wire holder keeper Superseded by part number: 657127R3
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
mach, mach. 5/16 x 3/4 Superseded by part number: 179816
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 15. |
657126R2
|
[2] |
HOLDER
|
IH
DISC, wire holder lower
|
| 16. |
657188R2
|
[2] |
NO LONGER SERVICED
|
IH
KNIFE, wire Superseded by part number: 657188R3
|
| . . |
17445R1
|
[4] |
BOLT,Hex, 5/16" - 18 x 1 1/4"
|
IH
mach. 5/16 x 1-1/4 Superseded by part number: 87657
|
| 17. |
219-36
|
[2] |
LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF
|
CAS
FITTING, lub. 1/8-45 Superseded by part number: 80717
|
| 18. |
332040
|
[6] |
LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg
|
WIN
FITTING, lub. 1/8-90 alemite 1613B
|
| 19. |
667438R1
|
[2] |
SHIM
|
IH
wire twister shaft, .020
|
| 19. |
667439R1
|
[6] |
SHIM
|
IH
wire twister shaft, .005 (or as req.)
|
| 20. |
656890R2
|
[1] |
CAM
|
IH
GEAR & STRIPPER CAM HOLDER, twister
|
| . . |
181435
|
[1] |
BOLT,Hex, 1/2" - 20 x 2", Gr 5
|
IH
SCREW, cap 1/2 NF x 2 Superseded by part number: 88848
|
| 21. |
658967R1
|
[2] |
SHIM
|
IH
disk pinion adj.
|
| 22. |
656946R1
|
[2] |
PINION
|
IH
wire clamp & cutter helical
|
| . . |
576485R1
|
[2] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
IH
Superseded by part number: 300868
|
| . . |
17080
|
[2] |
PIN, roll, 5/32 x 1-1/4
|
|
| 23. |
656949R1
|
[2] |
GEAR
|
IH
SHAFT, disk pinion
|
| . . |
Q3478
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 14 ga. Superseded by part number: 495-81038
|
| . . |
Q3501
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga. Superseded by part number: 95-81056
|
| 24. |
656912R2
|
[2] |
DISC
|
IH
PINION, disk
|
| . . |
657197R1
|
[2] |
LOCK PIN,1/4" x 2 1/4", Slotted
|
IH
Pin, 1/4" x 2 1/4", Slotted Superseded by part number: 88078
|
| . . |
17141R1
|
[4] |
LOCK PIN,5/32" x 1", Slotted
|
IH
Pin, 5/32" x 1", Slotted Superseded by part number: 38-11016
|
| 25. |
656894R12
|
[1] |
TWISTER
|
IH
ARM. R.H.
|
| 25. |
656894R1
|
[1] |
TWISTER
|
IH
FRAME, wire twister R.H.
|
| 26. |
664760R1
|
[1] |
CAM
|
IH
GEAR, trip dog carrier & wire twister
|
| 27. |
663378R1
|
[1] |
PAWL
|
IH
DOG, auxiliary trip
|
| 28. |
664947R1
|
[1] |
PIVOT
|
IH
trip dog
|
| . . |
Q134
|
[1] |
WASHER, 15/32 x 13/16 x 18 ga (or as required)
|
|
| . . |
588099R1
|
[1] |
WASHER
|
IH
15/32 x 3/4 x 22 ga (or as required)
|
| 29. |
R1003
|
[1] |
SPRING
|
IH
auxiliary trip dog
|
| 31. |
V341
|
[1] |
PAWL
|
IH
ROLLER, trip dog
|
| 32. |
663478R11
|
[1] |
PAWL
|
IH
DOG & ROLLER, trip
|
| 33. |
V690
|
[1] |
PIN
|
IH
STUD, trip dog roller
|
| 34. |
V680
|
[1] |
SPRING
|
IH
trip dog Superseded by part number: 753027R1
|
| 35. |
666754R1
|
[1] |
WASHER
|
IH
RETAINER, twister drive gear, 501G thru 4164H
|
| . . |
668787R1
|
[4] |
SCREW,Hex Soc Hd, 1/4"-20 x 1/2"
|
IH
1/4 x 1/2 nylock hex-soc-hd
|
| 36. |
664820R1
|
[2] |
WASHER
|
IH
twister drive gear, 501G thru 4164H
|
| 37. |
667826R1
|
[2] |
BUSHING
|
IH
knotter drive gear, 501G thru 4164H
|
| 39. |
667842R11
|
[1] |
|
P
GEAR W/BUSHINGS, twister drive 501G thru 4164H
|
| 40. |
667844R1
|
[1] |
BUSHING
|
IH
twister shaft
|
| 42. |
667843R91
|
[1] |
|
P
SUPPORT W/BUSHING, twister and gear insert 501G thru 4164H
|
| . . |
179885
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
Superseded by part number: 87689
|
| 43. |
274510
|
[1] |
FITTING
|
IH
1/4 90 deg lub Superseded by part number: 16964R91
|
| 44. |
109461
|
[8] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 45. |
657001R1
|
[2] |
BUSHING
|
IH
wire holder shaft
|
| 46. |
658735R2
|
[1] |
|
P
PIVOT & SUPPORT STRIPPER ACTUATING ARM
|
| . . |
17471R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/2"
|
IH
mach. 3/8 x 1-1/2 Superseded by part number: 179843
|
| 47. |
11309N
|
[2] |
SPACER
|
IH
twister cover
|
| . . |
19570R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 2
|
IH
1/4-20 x 5/8 cd-pltd hex-hd mach Superseded by part number: 280641
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
120392
|
[2] |
WASHER,1/4", SAE
|
IH
9/32 x 5/8 x 16 ga C-Z Superseded by part number: 87361
|
| 48. |
667784R91
|
[1] |
NO LONGER SERVICED
|
IH
COVER, twister cpt. Superseded by part number: 667784R92
|
| 49. |
658737R91
|
[1] |
ARM
|
IH
stripper actuating cpt.
|
| . . |
10366H
|
[2] |
WASHER
|
IH
21/32 x 1-/12 x 22 ga.
|
| . . |
103385
|
[1] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| 50. |
656952R1
|
[1] |
ROLLER
|
IH
stripper arm
|
| 51. |
658740R1
|
[1] |
SUPPORT
|
IH
ADJUSTMENT STRIPPER ACTUATING ARM
|
| . . |
15563R1
|
[2] |
BOLT,3/8"-16 x 1 1/4", G2, Full Thd
|
IH
PLOW, (#3) 3/8"-16 x 1 1/4", G2, Full Thd Superseded by part number: 19031R1
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga. Superseded by part number: 86632580
|
| 52. |
667787R1
|
[1] |
SPRING
|
IH
twister cover
|
| . . |
110638
|
[2] |
RIVET
|
IH
button hd. 3/16 x 5/16
|
| 53. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, lub. 1/4-28 str self tapping
|
| 55. |
669630R91
|
[1] |
SUPPORT
|
IH
W/BUSHING, twister and gear insert 4165H and up
|
| 57. |
669632R11
|
[1] |
|
P
GEAR W/BUSHING, twister drive, 4165H and up
|
| 59. |
271255R91
|
[1] |
BALL BEARING
|
IH
BEARING, twister drive gear, 4165H and up Superseded by part number: 87591960
|
| 60. |
287049R1
|
[1] |
SNAP RING,#196, Ext
|
IH
Ring, Snap, , twister drive gear bearing, 4165H and up #196, Ext Superseded by part number: 9671310
|
| 61. |
657206R1
|
[1] |
KEY,3/8" Sq x 2 3/8", Par
|
CAS
sq. 3/8 x 2-3/8
|
| 62. |
Q72
|
[1] |
KEY,5/16" Sq x 1 7/8", Par
|
IH
sq. 3/8 x 1-7/8
|
