| 1. |
667810R11
|
[1] |
NO LONGER SERVICED
|
IH
FRAME W/BUSHINGS, knotter drive Superseded by part number: 667810R21
|
| . . |
17552R1
|
[1] |
BOLT, hex 5/8 x 2-1/4
|
|
| . . |
17578R1
|
[1] |
BOLT (SPREADER),Hex, 5/8"-11 x 2 1/2", G2
|
IH
BOLT, 5/8 x 2-1/2 hex-hd mach Superseded by part number: 271564
|
| . . |
102639
|
[2] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
578274R1
|
[1] |
WASHER
|
IH
21/32 x 1 x 11 ga. Superseded by part number: 87613215
|
| . . |
17471R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/2"
|
IH
mach. 3/8 x 1-1/2 Superseded by part number: 179843
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
17448R1
|
[1] |
BOLT (SPREADER)
|
IH
BOLT, mach. 1/2 x 1-1/4 Superseded by part number: 271559
|
| . . |
17498R1
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 2
|
CAS
mach. 1/2 x 1-3/4
|
| . . |
102637
|
[2] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[3] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 2. |
109461
|
[2] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 3. |
667811R1
|
[4] |
BUSHING
|
IH
trip arm stud
|
| 4. |
667234R1
|
[2] |
PLATE
|
IH
stripper finger guide
|
| . . |
181364
|
[2] |
BOLT,Hex, 3/8" - 24 x 1", Gr 5
|
IH
SCREW, cap 3/8 NF x 1 Superseded by part number: 88374
|
| . . |
103026
|
[2] |
NUT,3/8"-24, G5
|
IH
Superseded by part number: 129-123
|
| 5. |
667235R1
|
[4] |
SPACER
|
IH
guide plate
|
| 6. |
667269R91
|
[1] |
FINGER
|
IH
stripper cpt. R.
|
| 7. |
660466R1
|
[2] |
WASHER
|
IH
stripper pivot stud
|
| 8. |
656956R1
|
[2] |
STUD
|
IH
stripper pivot front
|
| . . |
28407K
|
[2] |
WASHER
|
IH
17/32 x 1-1/4 x .22 ga
|
| 9. |
667237R91
|
[1] |
JOINT
|
IH
BALL JOINT stripper connecting rod 3/8
|
| 10. |
656932R1
|
[1] |
ROD
|
IH
wire stripper connecting
|
| 11. |
659567R91
|
[1] |
JOINT TURNING
|
IH
BALL JOINT STRIPPER CONNECTING ROD 7/16
|
| . . |
667596R1
|
[1] |
NUT
|
IH
lock 7/16 NF
|
| . . |
103322
|
[1] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 12. |
656930R2
|
[1] |
ROD
|
IH
stripper actuating
|
| . . |
425-117
|
[2] |
NUT,7/16"-20, G5
|
CAS
7/16 NF Superseded by part number: 50456
|
| 13. |
658742R1
|
[1] |
CLEVIS COUPLING
|
IH
CLIP, stripper clevis pin
|
| 14. |
116537
|
[1] |
SPACER
|
PA
CLEVIS, stripper actuating rod
|
| 15. |
658741R1
|
[1] |
PIN
|
IH
stripper clevis
|
| 16. |
667236R91
|
[1] |
CONNECTOR, ELEC
|
IH
BALL JOINT, sripper conn. rod
|
| 17. |
667230R91
|
[1] |
FINGER
|
IH
stripper cpt. L.
|
| 18. |
667233R1
|
[2] |
ANCHOR
|
IH
stripper finger
|
| . . |
156513
|
[4] |
SCREW,Cross Flat Hd, 3/8" - 16 x 1/2"
|
IH
fl-hd cross recess cd-pl 3/8
|
| . . |
575808R1
|
[4] |
WASHER
|
IH
19/32 x 1 x 16 ga.
|
| 19. |
657115R1
|
[2] |
FINGER
|
IH
INSERT, twister frame
|
| . . |
15563R1
|
[4] |
BOLT,3/8"-16 x 1 1/4", G2, Full Thd
|
IH
PLOW, (#3) 3/8"-16 x 1 1/4", G2, Full Thd Superseded by part number: 19031R1
|
| 20. |
495929R1
|
[2] |
NO LONGER SERVICED
|
IH
WEDGE, hay retainer narrow Superseded by part number: 495929R2
|
| . . |
15039R1
|
[4] |
BOLT
|
IH
cge. 3/8 x 1-1/2 Superseded by part number: 18685R1
|
| 21. |
495930R1
|
[1] |
WEDGE
|
IH
hay retainer wide
|
| . . |
15040R1
|
[2] |
BOLT,Sht Sq Nk, 7/16" - 14 x 1 1/2"
|
IH
cge. 7/16 x 1-1/2 Superseded by part number: 111-421
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
7/16
|
| 22. |
667834R1
|
[1] |
|
P
SUPPORT, twister shaft bearing
|
| . . |
17496R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 3/4"
|
IH
3/8-16 x 1-3/4 hex-hd mach
|
| . . |
Q1504
|
[3] |
WASHER
|
IH
13/32 x 7/8 x 16 ga Superseded by part number: 495-21044
|
| 23. |
667839R1
|
[1] |
SUPPORT
|
IH
PLATE, twister shaft bearing support Superseded by part number: 667839R2
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, cge. 3/8 x 1
|
| . . |
17446R1
|
[2] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach. 3/8 x 1-1/4 Superseded by part number: 88011
|
| 24. |
664754R3
|
[1] |
PLATE
|
IH
wire twister base Superseded by part number: 664754R4
|
| . . |
86508749
|
[2] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
|
GI
BOLT, cge. 3/8 x 1-1/4
|
| . . |
15581R1
|
[3] |
BOLT,3/8"-16 x 1 1/2", G2
|
IH
plow, 3/8 x 1-1/2 Superseded by part number: 19021R1, 118-141
|
| 25. |
665192R1
|
[2] |
SPRING
|
IH
hay retainer
|
| 26. |
667449R1
|
[2] |
RETAINER
|
IH
top hay
|
| . . |
Q3534
|
[2] |
HEADED PIN,9.53mm OD x 38.1mm L
|
IH
PIN, std. hd. 3/8 x 1-1/2
|
| . . |
103384
|
[2] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 27. |
667827R11
|
[2] |
|
P
BRACKET, top hay retainer cpt.
|
| . . |
17412R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
mach. 3/8 x 3/4 Superseded by part number: 86500692
|
| 28. |
667840R1
|
[1] |
|
P
SPACER, twister drive frame
|
| 29. |
656945R1
|
[2] |
BEARING
|
IH
BUSHING, stripper pivot
|
| . . |
Q1597
|
[6] |
WASHER
|
IH
13/32 x 3/4 x 16 ga. Superseded by part number: 86632580
|
| 30. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4-28 45 deg angle self tap lub
|
| 31. |
671121R1
|
[1] |
DEFLECTOR
|
IH
wire twister LH, used on 47 Baler
|
| . . |
18697R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 1 3/4", Gr 2
|
IH
BOLT, 7/16 x 1-3/4 znd sq-nk crg Superseded by part number: 86508778
|
| . . |
271501
|
[1] |
SOCKET
|
NNA
NUT, 7/16-14 znd hex.
|
| . . |
21029R1
|
[1] |
WASHER
|
IH
15/32 x 1 x 11 ga C-Z Superseded by part number: 495-81009
|
| 32. |
671122R1
|
[1] |
DEFLECTOR
|
IH
wire twister RH, used on 47 Baler
|
| . . |
19021R1
|
[1] |
CARRIAGE BOLT,#3, 3/8" - 16 x 1 1/2", Gr 2
|
IH
BOLT, 3/8 x 1-1/2 znd No. 3 plow Superseded by part number: 419-3624
|
| . . |
120377
|
[1] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
671120R92
|
[1] |
|
P
WIRE TWIST CONVERSION PACKAGE, used on 47 Baler, consists of reference No. 31, 32, 32 and 33
|
