纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (05-009) - HYD LINES, ARM 3.0M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
514 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YB01V00011F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, BUCKET |
| . . | YN12B00121F2 | [1] | CYLINDER INSTAL | |
| A2. | HS18C16140G1 | [1] | SCREW | KOBCAP Superseded by part number: HS18C16140G2 |
| A3. | ZN18C16013 | [2] | NUT | KOB |
| A5. | YN12B01122D1 | [1] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| A6. | YN12B01122D2 | [1] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| A7. | YN12B01122D3 | [1] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| A8. | YN12B01348P2 | [1] | PIN | KOB |
| . . | YB43H00008F1 | [1] | HYD LINES, CYLINDER | |
| B1. | LQ43H01029P2 | [1] | TUBE | KOB |
| B2. | YB43H01013P1 | [1] | RIGID TUBE | KOB |
| B3. | YN43H01097P1 | [1] | CLAMP | KOB |
| B4. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBCAP |
| B5. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B6. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBCAP |
| B7. | ZD12P02600 | [2] | O-RING | KOB |
| B8. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| B9. | ZG91U02000 | [1] | LUBE NIPPLE | KOBGREASE |
| B10. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| B11. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | YB43H00001F2 | [1] | HYD LINES,ARM | |
| C2. | ZX50H12165 | [2] | HOSE | KOBHOSE |
