凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-05) - MAIN FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
189 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
668589R1
|
[1] |
|
P
GUSSET, axle center
|
| 2. |
663355R1
|
[2] |
|
P
BUMPER, needle
|
| 3. |
663433R1
|
[1] |
|
P
BRACKET, needle bumper
|
| 4. |
663351R1
|
[1] |
|
P
SPACER, needle bumper bracket
|
| 5. |
663303R93
|
[1] |
|
P
FRAME ASSY, left main
|
| 6. |
663304R93
|
[1] |
|
P
FRAME ASSY, right main
|
| . . |
Q530
|
[1] |
HEADED PIN,7.92mm OD x 63.5mm L
|
IH
PIN, 5/16 x 2-1/2 std-hd
|
| 7. |
663535R1
|
[1] |
|
P
ANGLE, cross conveyor
|
| . . |
557265R1
|
[1] |
WASHER
|
IH
11/32 x 1 x 11 ga Superseded by part number: 19-1025
|
| 8. |
663458R1
|
[1] |
|
P
BRACE, frame
|
| 9. |
663536R1
|
[1] |
|
P
ANGLE, frame cross
|
| 10. |
663526R92
|
[1] |
|
P
BRACE ASSY, diagonal
|
| 11. |
663538R2
|
[1] |
|
P
GUSSET, cross conveyor
|
