| 1. |
663335R3
|
[1] |
|
P
SIDE, bale chamber left
|
| 2. |
665347R1
|
[2] |
WEDGE
|
IH
hay retainer long, 3744M and below
|
| 3. |
663451R1
|
[4] |
|
P
ROD, bale chamber tie
|
| 4. |
663436R1
|
[1] |
|
P
ANGLE, main drive support lower left
|
| 5. |
663417R1
|
[1] |
|
P
EXTENSION, bottom plate left
|
| 6. |
663432R1
|
[1] |
|
P
RUNNER, plunger lower left
|
| 7. |
656917R1
|
[3] |
|
P
WEDGE, hay retainer
|
| 8. |
674705R1
|
[1] |
|
P
PLATE, hay retainer, 3745N and up
|
| . . |
18508R1
|
[1] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8-16 x 3/4 znd sq-nk crg Superseded by part number: 86508748
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT,3/8-16 x 1 znd sq-nk crg Superseded by part number: 88682
|
| . . |
111-404
|
[1] |
CARRIAGE BOLT,Short NK, 7/16"-14 x 1 1/4", G5
|
CAS
BOLT, 7/16-14 x 1-1/4 sq-nk crg Superseded by part number: 86508777
|
| . . |
120377
|
[3] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
664646R1
|
[1] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex. lock Superseded by part number: 280980
|
| . . |
120382
|
[3] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
103322
|
[1] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
