| 1. |
664534R2
|
[1] |
RUNNER
|
IH
plunger guide lower right
|
| . . |
Q1505
|
[6] |
WASHER
|
IH
13/32 x 1 x 16 ga Superseded by part number: 495-21044
|
| 2. |
663423R1
|
[1] |
|
P
EXTENSION, bottom plate right
|
| 3. |
663336R2
|
[1] |
|
P
SIDE, bale chamber right front
|
| 4. |
663435R1
|
[1] |
|
P
GUIDE, plunger upper right
|
| 5. |
663425R2
|
[1] |
|
P
GUIDE, plunger upper
|
| 6. |
663473R2
|
[1] |
|
P
ANGLE, lower right support
|
| . . |
615063R1
|
[2] |
WASHER
|
IH
15/32 x 7/8 x 16 ga
|
| 7. |
668576R1
|
[1] |
|
P
SHIM, stationary knife
|
| 8. |
665347R1
|
[2] |
WEDGE
|
IH
hay retainer long, 3744M and below
|
| 9. |
663337R3
|
[1] |
|
P
SIDE, bale chamber right rear
|
| 10. |
656917R1
|
[3] |
|
P
WEDGE, hay retainer
|
| 11. |
663419R1
|
[1] |
KNIFE ASSY
|
IH
KNIFE, stationary shear
|
| 12. |
668602R91
|
[1] |
|
P
CHANNEL ASSY, feed opening sill
|
| 13. |
663424R2
|
[1] |
GUIDE
|
IH
plunger lower right
|
| 14. |
664545R1
|
[1] |
|
P
SHIM, plunger thrust spacer lower
|
| 15. |
667934R1
|
[2] |
BOLT (SPREADER)
|
IH
BOLT, plunger guide eye
|
| . . |
557950R1
|
[3] |
WASHER
|
IH
13/32 x 1 x 7 ga Superseded by part number: 21843R1
|
| 16. |
674705R1
|
[1] |
|
P
PLATE, hay retainer, 3745N and up
|
| . . |
18508R1
|
[3] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8-16 x 3/4 sq-nk crg Superseded by part number: 86508748
|
| . . |
120377
|
[3] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[3] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
15040R1
|
[1] |
BOLT,Sht Sq Nk, 7/16" - 14 x 1 1/2"
|
IH
7/16-14 x 1-1/2 sq-nk crg Superseded by part number: 111-421
|
| . . |
664646R1
|
[1] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex. lock Superseded by part number: 280980
|
| . . |
103322
|
[1] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
