凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-12) - LIFTING JACK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
955 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
668583R1
|
[2] |
|
P
BRACE, jackstand
|
| . . |
474848R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 cd-pltd lock Superseded by part number: 231-4218
|
| . . |
22656R1
|
[2] |
WASHER
|
IH
17/32 x 1-1/16 x 16 ga CDP Superseded by part number: 25710R1
|
| 2. |
668584R91
|
[1] |
|
P
LUG ASSY, jack mount
|
| . . |
664646R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 lock Superseded by part number: 280980
|
| 3. |
668581R91
|
[1] |
|
P
JACK ASSY, lifting, for service replacement of 668581R91 order jack, 665067R91, pivot, 665068R91, snap ring, 665071R1
|
| . . |
671034R1
|
[1] |
PIN
|
IH
1/2 x 1-1/2 C-Z std-hd Superseded by part number: 86624070
|
| 4. |
668582R91
|
[1] |
|
P
PAD ASSY, jack
|
| . . |
671035R1
|
[1] |
|
P
PIN, 1/2 x 3-3/4 C-Z std-hd
|
