| 1. |
668586R91
|
[1] |
|
P
PIVOT ASSY, bale chamber extension
|
| . . |
15009R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd Superseded by part number: 412-716
|
| . . |
664646R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 lock Superseded by part number: 280980
|
| . . |
W6652
|
[2] |
WASHER
|
IH
15/32 x 1 x 16 ga Superseded by part number: 495-81158
|
| 2. |
668580R1
|
[1] |
|
P
EXTENSION, bale chamber right
|
| 3. |
663254R92
|
[1] |
|
P
CHANNEL ASSY, lower tension
|
| . . |
Q625
|
[1] |
|
P
PIN, 1/2 x 5-7/8 std-hd
|
| 4. |
495526R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN ASSY, bale chamber extension holdup
|
| . . |
668986R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 short sq-nk crg, type 2 Superseded by part number: 280827
|
| . . |
657803R1
|
[2] |
|
P
NUT, 5/16-18 wing
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| . . |
Q5028
|
[2] |
WASHER
|
IH
15/32 x 1 x 11 ga Superseded by part number: 195-2041
|
| 5. |
668579R1
|
[1] |
|
P
EXTENSION, bale chamber left
|
| 1. |
663402R1
|
[1] |
|
P
SHIELD, needle arm BALE COUNTER
|
| 2. |
495046R92
|
[1] |
COUNTER
|
IH
W/ATTACHING HARDWARE, bale BALE COUNTER
|
| . . |
142862
|
[2] |
SCREW,Type U Metallic, Rnd Hd, #4 x 1/4"
|
IH
No. 4 x 1/4 drive BALE COUNTER Superseded by part number: 86598785
|
| 3. |
656707R91
|
[1] |
ARM
|
IH
ASSY, bale counter
|
| 4. |
495525R1
|
[1] |
SPRING
|
IH
bale counter
|
