| 1. |
663489R1
|
[1] |
|
P
ANGLE, needle guard right
|
| 2. |
495248R91
|
[2] |
BRAKE
|
IH
ASSY, needle, for wire balers only
|
| . . |
Q1505
|
[8] |
WASHER
|
IH
13/32 x 1 x 16 ga Superseded by part number: 495-21044
|
| 3. |
495250R1
|
[2] |
|
P
RETARDER, needle, for wire balers only
|
| . . |
136143
|
[12] |
PIN
|
BER
RIVET, 3/16 x 7/16 ov-hd tubular
|
| 4. |
668577R91
|
[1] |
|
P
PLATE ASSY, bottom
|
| 5. |
663347R1
|
[2] |
|
P
SPACER, bottom plate brace
|
| 6. |
663643R1
|
[1] |
|
P
BRACE, bottom plate rear
|
| 7. |
665722R1
|
[1] |
|
P
STRAP, bale chamber stiffener
|
| 8. |
H39195
|
[1] |
SPRING
|
IH
plunger stop pivot
|
| 9. |
668048R1
|
[1] |
CLIP
|
IH
plunger stop spring
|
| . . |
350515R1
|
[1] |
WASHER
|
IH
21/32 x 1 x 16 ga Superseded by part number: 495-81176
|
| 10. |
664152R91
|
[1] |
|
P
ARM ASSY, plunger stop
|
| . . |
Q5035
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga Superseded by part number: 495-81254
|
| 11. |
667962R1
|
[1] |
|
P
HANGER, plunger stop arm
|
| 12. |
127786
|
[1] |
ADJUSTABLE CLEVIS,5/16"-18 x 4 15/16"
|
IH
CLEVIS, 5/8-18 x 4-15/16 hv adj rod end Superseded by part number: 213-2110
|
| . . |
PO26455
|
[1] |
LARGE PIN,5/8" x 1 7/8"
|
IH
PIN, 5/8 x 1-7/8 std-hd Superseded by part number: 540874R1
|
| 13. |
657143R1
|
[1] |
|
P
ANGLE, needle guard left
|
| 14. |
663415R1
|
[1] |
|
P
BRACE, bottom plate front
|
| 15. |
665577R1
|
[1] |
|
P
LINK, plunger stop
|
| 16. |
667685R1
|
[1] |
PIN
|
IH
hay retainer
|
| 17. |
662007R2
|
[2] |
RETAINER
|
IH
hay
|
| 18. |
668869R1
|
[2] |
SPRING
|
IH
hay retainer
|
| 19. |
301265R1
|
[1] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 2 3/4" lg
|
IH
FITTING, 1/8-27 NPTF 67-1/2 deg angle lub Superseded by part number: 219-42
|
| 20. |
444304
|
[1] |
SCREW
|
SM
ADAPTER, 1/8-27 automotive pipe Superseded by part number: 71452869
|
| 21. |
454417R1
|
[1] |
SNAP RING,#100, Ext
|
IH
Ring, Snap, , plunger stop pivot #100, Ext Superseded by part number: 25121
|
| 22. |
667954R1
|
[1] |
|
P
PIVOT, plunger stop
|
| . . |
615226R1
|
[2] |
WASHER
|
IH
1-1/32 x 1-1/2 x 22 ga, (or as required) Superseded by part number: 86624168
|
| 23. |
11453P
|
[1] |
PIN
|
IH
plunger stop pivot lock
|
| 24. |
667952R1
|
[1] |
STOP
|
IH
plunger
|
