凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-14) - FLYWHEEL AND FLYWHEEL HUB Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
366 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663357R1
|
[1] |
BOLT (SPREADER)
|
IH
BUSHING, flywheel shear bolt
|
| 2. |
663345R1
|
[1] |
|
P
WASHER, flywheel
|
| 3. |
663144R11
|
[1] |
|
P
FLYWHEEL W/BUSHING
|
| 4. |
663439R1
|
[1] |
BUSHING
|
IH
flywheel
|
| 5. |
665080R21
|
[1] |
|
P
HUB ASSY, flywheel
|
| 6. |
181348
|
[1] |
BOLT,Hex, 5/16" - 24 x 2 1/4", Gr 5
|
IH
SHEAR BOLT, 5/16-24 x 2-1/4 hex-hd cap screw Superseded by part number: 27292R1
|
| 7. |
668870R1
|
[1] |
BUSHING
|
IH
flywheel hub shear bolt
|
| . . |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF, In flywheel 1/8"-27 x .66 lg Superseded by part number: 80710
|
