| 1. |
517645R11
|
[1] |
COLLAR
|
IH
bearing locking Superseded by part number: 47577188
|
| 2. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
packer drive shaft bearing
|
| 3. |
571588R91
|
[1] |
BALL BEARING
|
IH
BEARING ASSY, packer drive Superseded by part number: 47066
|
| 4. |
659380R1
|
[2] |
SNAP RING,#137, Ext
|
IH
Ring, Snap, , packer drive shaft #137, Ext Superseded by part number: 9671424
|
| 5. |
668896R1
|
[1] |
|
P
PINION, packer crank
|
| . . |
452563
|
[1] |
KEY
|
IH
5/16 x 2-1/8 Woodruff 128 Superseded by part number: 57388D
|
| 6. |
664533R2
|
[1] |
|
P
SHAFT, packer drive front
|
| . . |
219758
|
[1] |
JAM NUT,Jam, 3/4"-10, G5
|
IH
3/4-16 hex. jam
|
| . . |
Q3775
|
[1] |
WASHER
|
IH
25/32 x 2 x 16 ga Superseded by part number: 195-109
|
| 7. |
ST568
|
[1] |
BALL BEARING,35 mm ID x 62 mm OD x 14 mm
|
IH
BEARING ASSY, packer drive shaft inner Superseded by part number: 28042470
|
| 8. |
663230R1
|
[1] |
|
P
GEAR, packer drive bevel
|
| 9. |
663341R1
|
[4] |
|
P
SHIM, packer drive shaft .010
|
| 9. |
663342R1
|
[8] |
|
P
SHIM, packer drive shaft .005
|
| 9. |
663343R1
|
[6] |
|
P
SHIM, packer drive shaft .007
|
| 10. |
663147R1
|
[1] |
|
P
HOUSING, packer crankshaft
|
| 11. |
663359R1
|
[1] |
|
P
SPACER, packer drive bearing
|
| 12. |
ST246
|
[1] |
BALL BEARING,30mm ID x 62mm OD x 16mm W
|
IH
BEARING ASSY, packer drive shaft outer
|
| 13. |
663358R1
|
[1] |
|
P
GASKET, packer drive bearing cap
|
| 14. |
663145R1
|
[1] |
|
P
CAP, packer drive bearing
|
| 15. |
663886R91
|
[1] |
|
P
SEAL, packer drive bearing oil
|
| 16. |
668894R11
|
[1] |
|
P
SHAFT ASSY, packer drive rear
|
| . . |
551769R1
|
[3] |
WASHER
|
IH
1-13/32 x 2 x 16 ga, (or as required) Superseded by part number: 495-81213
|
| 17. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self tap. str lub
|
