| 1. |
668627R1
|
[1] |
|
P
TRUNNION, packer relief
|
| 2. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 3. |
668622R91
|
[1] |
|
P
ANCHOR ASSY, packer relief
|
| 4. |
668626R11
|
[1] |
|
P
SUPPORT ASSY, packer relief
|
| 5. |
663903R1
|
[1] |
|
P
BOLT, packer finger guide
|
| 6. |
663902R1
|
[1] |
VALVE SPRING
|
IH
SPRING, packer finger relief
|
| 7. |
663904R1
|
[1] |
|
P
NUT, packer relief guide
|
| 8. |
669641R1
|
[1] |
|
P
SUPPORT, packer finger
|
| . . |
C351
|
[1] |
AXLE PIN
|
IH
PIN, 1/2 x 2-3/8 std-hd Superseded by part number: 439-5838
|
| 9. |
662632R1
|
[1] |
SPRING
|
IH
packer, 501G thru 1599H Superseded by part number: 1970961C1
|
| 9. |
69983D
|
[1] |
SPRING
|
IH
packer, 1600K up
|
| 10. |
663154R1
|
[1] |
BUSHING
|
IH
BEARING, packer crank front
|
| 11. |
663152R2
|
[1] |
|
P
GEAR, packer crank
|
| 12. |
662555R1
|
[1] |
BUSHING,8.46mm ID x 15.98mm OD x 12.83mm L
|
IH
packer finger
|
| 13. |
663176R11
|
[1] |
|
P
FINGERS W/BUSHINGS, packer
|
| 14. |
668618R1
|
[1] |
|
P
GEAR, knotter & twister drive pinion
|
| . . |
Q81
|
[1] |
KEY,Gib, 3/8" Sq x 1 3/4"
|
IH
3/8 x 1-3/4 gib
|
| . . |
Q275
|
[5] |
WASHER
|
IH
1-13/32 x 2 x 20 ga Superseded by part number: 495-81213
|
| 15. |
663222R92
|
[1] |
|
P
CRANK ASSY, packer
|
| . . |
Q121
|
[2] |
WASHER
|
IH
1-9/32 x 2 x 16 ga Superseded by part number: 495-81205
|
| . . |
551769R1
|
[4] |
WASHER
|
IH
1-13/32 x 2 x 16 ga Superseded by part number: 495-81213
|
| 16. |
663142R1
|
[1] |
|
P
CAP, packer finger bearing
|
| 17. |
662032R2
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR, packer finger relief
|
| . . |
663047R2
|
[2] |
PIN
|
IH
3/4 x 2-5/32 rod end
|
| . . |
664840R1
|
[1] |
RING
|
IH
PIN, 3/16 quick attachable
|
| 18. |
667439R1
|
[4] |
SHIM
|
IH
knotter & twister drive pinion .005, (or as required)
|
| 18. |
667438R1
|
[6] |
SHIM
|
IH
knotter & twister drive pinion .020, (or as required)
|
| 19. |
181348
|
[1] |
BOLT,Hex, 5/16" - 24 x 2 1/4", Gr 5
|
IH
SHEAR BOLT, 5/16-24 x 2-1/4 hex-hd cap screw Superseded by part number: 27292R1
|
| 20. |
219-36
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF
|
CAS
FITTING, 1/8-27 PTF 45 deg angle lub Superseded by part number: 80717
|
| 22. |
673878R1
|
[1] |
|
P
RETAINER, packer finger shear bolt
|
