| 1. |
ST1300
|
[4] |
BEARING
|
IH
ASSY, auger core & drive Superseded by part number: 562708R91
|
| 2. |
663362R1
|
[2] |
BUSHING
|
IH
auger drive shaft outer
|
| 3. |
657082R4
|
[1] |
GEAR
|
IH
PINION, auger drive
|
| . . |
120502
|
[1] |
STOP
|
IH
3/16 x 7/8 Woodruff No. 11 Superseded by part number: 126-119
|
| . . |
142535
|
[1] |
GROOVED PIN,5/16" x 2", Type A
|
IH
Pin, Grooved, 5/16" x 2", Type A Superseded by part number: 38-32032
|
| 4. |
663363R1
|
[1] |
BUSHING
|
IH
auger drive shaft
|
| 5. |
663413R1
|
[1] |
SHAFT
|
IH
auger drive pinion
|
| . . |
VC649
|
[1] |
WASHER
|
IH
29/32 x 1-3/4 x 16 ga
|
| . . |
552455R1
|
[1] |
|
P
WASHER, 1-1/16 x 1-3/4 x 22 ga
|
| 6. |
663429R1
|
[1] |
|
P
COUPLING, auger drive shaft
|
| . . |
103384
|
[3] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| . . |
U5350
|
[2] |
|
P
PIN, 5/16 x 1-11/16 std-hd
|
| . . |
W6571
|
[1] |
|
P
PIN, 3/8 x 1-11/16 std-hd
|
| 7. |
657191R1
|
[2] |
|
P
BUSHING, auger relief
|
| . . |
Q1505
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga Superseded by part number: 495-21044
|
| 8. |
663520R93
|
[1] |
|
P
SUPPORT ASSY, auger
|
| . . |
615325R1
|
[1] |
|
P
WASHER, 1-11/16 x 2-1/4 x 16 ga
|
| 9. |
663515R93
|
[1] |
|
P
AUGER ASSY, hay
|
| 10. |
109461
|
[3] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 11. |
655727R1
|
[1] |
|
P
STOP, auger
|
| 12. |
655726R1
|
[1] |
|
P
HOLDER, auger stop
|
| 13. |
657160R1
|
[2] |
PULLEY
|
IH
SHEAVE, auger drive rear
|
| 14. |
657079R1
|
[2] |
|
P
HUB, V-sheave
|
| . . |
Q3915
|
[2] |
KEY,Gib, 1/4" Sq x 1 5/8"
|
IH
1/4 x 1-5/8 gib
|
| . . |
Q397
|
[32] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| 15. |
663480R1
|
[1] |
|
P
V-BELT, Auger drive
|
| 16. |
657150R11
|
[1] |
|
P
SHIELD W/PRODUCT GRAPHIC, auger drive
|
| 17. |
495480R1
|
[2] |
PULLEY
|
IH
SHEAVE, auger drive front
|
| 18. |
665187R1
|
[1] |
THRUST WASHER
|
IH
auger thrust
|
| 19. |
668608R1
|
[1] |
|
P
SHAFT, auger drive
|
| 20. |
1904B
|
[1] |
COLLAR, auger stop
|
|
| . . |
272120
|
[1] |
CONNECTING LINK
|
NNA
7/16-14 hex. jam Superseded by part number: 25-147, 25-147, NLS
|
| . . |
102962
|
[1] |
SCREW, 7/16-14 x 1 sq-hd cone-pt set
|
|
| 21. |
660115R1
|
[1] |
INSULATOR BLOCK
|
IH
BUMPER, auger
|
| . . |
575807R1
|
[1] |
WASHER
|
IH
13/32 x 1 x 11 ga Superseded by part number: 95-81086
|
| 22. |
663445R1
|
[1] |
|
P
BRACKET, auger bumper
|
| 23. |
662632R1
|
[1] |
SPRING
|
IH
auger helper Superseded by part number: 1970961C1
|
| 24. |
662387R1
|
[1] |
ANCHOR
|
IH
auger helper spring
|
