凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-20) - CROSS CONVEYOR PLATFORM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
908 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663490R1
|
[1] |
|
P
SUPPORT, cross conveyor
|
| 2. |
663549R1
|
[1] |
|
P
BOTTOM & BACK, feed opening
|
| . . |
125678
|
[9] |
BOLT
|
IH
SCREW, 5/16-18 x 5/8 slt-truss-hd mach Superseded by part number: 182-515
|
| . . |
114663
|
[5] |
SCREW,Sl Flat Hd, 5/16" - 18 x 3/4"
|
IH
5/16-18 x 3/4 slt-f-hd mach Superseded by part number: 473-13112
|
| . . |
120272
|
[3] |
SCREW
|
NH
5/16-18 x 1 cd-pltd slt-truss hd mach
|
| 3. |
668610R1
|
[1] |
|
P
SHIELD, auger drive gear
|
| . . |
125681
|
[2] |
|
P
SCREW, 5/16-18 x 5/8 cd-pltd truss hd mach
|
| 4. |
657141R1
|
[1] |
|
P
ANGLE, feed opening
|
| 5. |
663551R91
|
[1] |
|
P
SHEET ASSY, feed opening front
|
| 6. |
663550R1
|
[1] |
|
P
COVER, cross conveyor
|
| 7. |
663431R1
|
[1] |
|
P
SUPPORT, cross conveyor & end sheet
|
| 8. |
663338R2
|
[1] |
|
P
SHEET, cross conveyor side
|
| 9. |
663539R1
|
[1] |
|
P
PLATFORM, cross conveyor
|
