凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-25) - PICKUP COVER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
659842R1
|
[2] |
|
P
STOP, pickup cover sheet
|
| . . |
1380S
|
[2] |
PIN
|
IH
5/16 x 1-3/4 std-hd Superseded by part number: 439-5528
|
| 2. |
659843R1
|
[2] |
|
P
WASHER, pickup cover adjusting
|
| 3. |
663475R1
|
[2] |
|
P
ARM, pickup cover sheet
|
| 4. |
659846R1
|
[1] |
|
P
SPRING, pickup cover left
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| 5. |
662394R1
|
[6] |
FINGER
|
IH
TINE, pickup cover
|
| 6. |
659845R1
|
[1] |
|
P
SPRING, pickup cover right
|
| 7. |
663465R1
|
[1] |
|
P
BRACE, feed opening front sheet
|
| 8. |
663523R91
|
[1] |
|
P
BRACKET ASSY, pickup cover tine
|
