凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-25[A]) - PICKUP WHEEL, STEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
344 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
274508
|
[1] |
LUBE NIPPLE
|
IH
FITTING, 1/4-28 NS 45 deg angle lub Superseded by part number: 87569
|
| 3. |
659918R1
|
[1] |
BUSHING
|
IH
pickup wheel
|
| 4. |
659917R91
|
[1] |
|
P
WHEEL ASSY, pickup
|
| 5. |
667723R91
|
[1] |
|
P
BRACKET ASSY, pickup wheel
|
| . . |
W6652
|
[1] |
WASHER
|
IH
15/32 x 1 x 16 ga Superseded by part number: 495-81158
|
| . . |
Q3501
|
[2] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga Superseded by part number: 95-81056
|
