| 1. |
668696R1
|
[1] |
|
P
SPACER, PTO drive gear
|
| 2. |
668996R91
|
[1] |
|
P
SET, 540 RPM gear, 37T, includes ref. 18
|
| 2. |
469248R2
|
[1] |
|
P
GEAR, 1000 RPM, 20T
|
| 3. |
663605R2
|
[2] |
SHIM
|
IH
gear .007
|
| 4. |
663596R1
|
[1] |
|
P
COVER, case
|
| . . |
18764R1
|
[6] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16-18 x 3/4 znd hex-hd mach Superseded by part number: 424-512
|
| . . |
80681
|
[6] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 5. |
618023R91
|
[4] |
BEARING ASSY,34.93mm ID x 18.2mm W
|
IH
BEARING ASSY, PTO case cone
|
| 6. |
618024R1
|
[4] |
BEARING CUP,65.113mm OD x 13.97mm W
|
IH
PTO case Superseded by part number: 86516467
|
| 7. |
663590R11
|
[1] |
|
P
SHAFT ASSY, input
|
| . . |
427646
|
[1] |
SLOTTED NUT,7/8"-14, G5
|
IH
NUT, 7/18-14 slt-hex Superseded by part number: 26963R1
|
| . . |
137204
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1 1/2" Superseded by part number: 80708
|
| . . |
21846R1
|
[1] |
WASHER, 29/32 x 2 x 3 ga C-Z
|
|
| . . |
21794R1
|
[1] |
WASHER
|
IH
1-13/32 x 2 x 20 ga C-Z Superseded by part number: 495-81212
|
| 8. |
378157R91
|
[2] |
OIL RESERVOIR
|
IH
SEAL, PTO case oil Superseded by part number: 380922R91
|
| 9. |
663586R3
|
[1] |
HOUSING
|
IH
BOX, gear Superseded by part number: 548052R1
|
| . . |
445763
|
[2] |
BOLT,M14 x 1.5 x 53mm, Class 10.9, BLK
|
ZED
PLUG, 3/8-18 automotive sq-hd pipe Superseded by part number: 9835360
|
| 10. |
91916R91
|
[1] |
BREATHER,3/8"-18 NPT, Short, w/washer
|
IH
gear box Superseded by part number: 87283549
|
| 11. |
663607R1
|
[1] |
GASKET
|
IH
PTO case cover
|
| 12. |
663601R1
|
[2] |
SHIM
|
IH
barrel case .020
|
| 12. |
663602R1
|
[2] |
SHIM
|
IH
barrel case .007
|
| 12. |
663603R1
|
[2] |
SHIM
|
IH
barrel case .005
|
| 13. |
663587R2
|
[1] |
|
P
BARREL, gear box
|
| . . |
18795R1
|
[5] |
BOLT,Hex, 7/16"-14 x 1 1/4", G2
|
IH
7/16-14 x 1-1/4 znd hex-hd mach Superseded by part number: 179860
|
| . . |
18796R1
|
[3] |
BOLT,Hex, 7/16"-14 x 1 1/2", G2
|
IH
7/16-14 x 1-1/2 C-Z hex-hd mach Superseded by part number: 179862
|
| . . |
271501
|
[3] |
SOCKET
|
NNA
NUT, 7/16-14 znd hex.
|
| . . |
120383
|
[8] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 14. |
663555R11
|
[1] |
|
P
PULLEY W/BUSHING, drive
|
| 15. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 16. |
663591R11
|
[1] |
|
P
SHAFT ASSY, output
|
| . . |
23044R1
|
[1] |
|
P
WASHER, 1-13/32 x 2-1/2 x 16 ga C-Z
|
| 17. |
662241R1
|
[2] |
RATCHET
|
IH
DOG, over running clutch Superseded by part number: 3101008R1
|
| . . |
18661R1
|
[2] |
BOLT,Hex, 1/4"-20 x 2-1/2", G2
|
IH
1/4-20 x 2-1/2 znd hex-hd mach Superseded by part number: 113-12
|
| . . |
120375
|
[2] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
23298R1
|
[2] |
PIN, 1/2 x 1-7/8 C-Z slt-spring
|
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
21870R1
|
[4] |
WASHER
|
IH
17/32 x 3/4 x 16 ga C-Z Superseded by part number: 495-81006
|
| 18. |
469392R2
|
[1] |
GEAR
|
IH
1000 RPM, 15T
|
| 19. |
663608R1
|
[1] |
|
P
SPACER, pulley
|
| 20. |
21876R1
|
[1] |
WASHER, 29/32 x 2-3/4 x 7 ga C-Z, replaces 495465R1
|
|
| 21. |
663737R1
|
[1] |
BUSHING
|
IH
pulley
|
| 22. |
663554R1
|
[1] |
DOOR
|
IH
CARRIER, dog
|
